QuickSpecs
HP EliteDisplay E242 24-inch Monitor
HP EliteDisplay E242 24-inch Monitor Head Only
Technical Specifications
c04820064 — DA – 15432 — Worldwide — Version 3 — May 9, 2016
Page 6
Ergonomic Features
- Not available on
head only model
Tilt Range
-5° to +25°
Swivel
±45°
Pivot
90°
Environmental
Temperature -
Operating
5° to 35° C (41° to 95° F)
Temperature - Non-
operating
–20° to 60° C (-4° to 140° F)
Humidity - Operating
20% to 80% non-condensing
Humidity - Non-
operating
5% to 95%, 38.7° C max wet-bulb
Altitude - Operating
0 to 5,000 m (0 to 16,400 ft)
Altitude – Non-
operating
0 to 12,192 m (0 to 40,000 ft)
White LED Backlights
Yes
CCFL Panel
No
Arsenic-Free Display
Glass
Yes
Low Halogen
1
Yes
Mercury-Free Display
Backlighting
Yes, Mercury-free LED backlighting
Environmental Data
Eco-Label Certifications
& declarations
This product has received or is in the process of being certified to the following approvals and may
be labeled with one or more of these marks:
 IT ECO declaration
 US ENERGY STAR®
 TCO 6.0 / TCO Certified Edge
 EPEAT® <Gold> registered in the United States. See http://www.epeat.net for registration
status in your country
Energy Consumption
(in accordance with US
ENERGY STAR® test
method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation
18.03 W
18.06 W
18.5 W
Sleep
0.5 W
0.44 W
0.5 W
Off
0.22 W
0.27 W
0.3 W
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation
62 BTU/hr
62 BTU/hr
63 BTU/hr
Sleep
2 BTU/hr
2 BTU/hr
2 BTU/hr
Off
1 BTU/hr
1 BTU/hr
1 BTU/hr
*NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.
