HP L1908w Specification

Panel Type 19-in (48.25-cm) Wide-Aspect Active Matrix TFT (thin film transistor)
Viewable Image Area
(diagonal)
19 in (48.25 cm) wide (WXGA+); diagonally measured
Screen Opening
(W x H)
16.1 x 10.1 in (40.98 x 25.67 cm)
Viewing Angle (typical) Up to 160° horizontal/160° vertical (10:1 minimum contrast ratio)
Brightness (typical) * 300 nits (cd/m
2
)
Contrast Ratio (typical) * 1000:1
Response Rate ≤5 ms (on/off)
Pixel Pitch 0.285 mm
Backlight Lamp Life
(to half brightness)
50 K hours
* All performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
On Screen Display
(OSD) Controls
Buttons or Switches Auto adjust/OSD down, OSD UP, OSD menu select, power
Languages English, French, German, Spanish, Italian, Dutch, and Japanese, S.
Chinese
User Controls Brightness, contrast, positioning, color temperature (6500k, 9300k,
custom), individual color control, serial number, display, clock, clock
phase, monitor management, factory reset, zoom
Signal Interface/
Performance
Horizontal Frequency 24 to 83 kHz
Vertical Frequency 50 to 76 Hz
Native Resolution 1440 x 900 @ 60 Hz
Preset VESA Graphic
Modes (non-interlaced)
1280 x 1024 @ 60 Hz and 75 Hz
1024 x 768 @ 60 Hz and 75 Hz
800 x 600 @ 60 Hz and 75 Hz
640 x 480 @ 60 Hz and 75 Hz
Text Mode 720 x 400 @ 70 Hz
Mac Mode 1152 x 870 @ 75 Hz and 832 x 624 @ 75 Hz
Sun Mode 1152 x 900 @ 66 Hz
Maximum Pixel Clock
Speed
140 MHz (analog input)
User Programmable
Modes
Yes, 10
Anti-Glare Yes
Anti-Static Yes
Default Color
Temperature
6500 K
Video Input Plug and Play Yes
Self Powered USB 2.0
Hub
No
Input Signal VGA
Input Impedance 75 ohms ± 10%
Sync Input TTL separate synch or Composite Sync
VGA Cable 15 pin D-sub VGA
VGA Cable Length 5.9 ft (1.8 m)
QuickSpecs
HP L1908w 19-inch Widescreen LCD Monitor
Technical Specifications
DA - 12826 Worldwide QuickSpecs — Version 3 — 12/17/2007 Page 2

HP L1908w Specifications

General

3D	No
Panel type	TFT
Pixel pitch	0.285 x 0.285 mm
Display surface	Matt
Display diagonal	19 \
Separate H/V sync	Yes
Display resolution	1440 x 900 pixels
Display technology	LCD
Native aspect ratio	16:10
Vertical scan range	50 - 76 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	24 - 83 kHz
Viewable size diagonal	482.5 mm
Viewable size, vertical	256.7 mm
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewable size, horizontal	409.8 mm
Viewing angle, horizontal	160 °
Display scanning frequency	Horizontal frequency: 24-83 kHz, Vertical frequency: 50-76 Hz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1440 x 900 (WXGA+)
I/O ports	VGA
HDMI ports quantity	0
Certification	TCO 03, Taiwan Green Mark, CECP
Product color	Black
Country of origin	China
Tilt angle range	-5 - 30 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, ITA, JPN
UNSPSC-code	43211902
Audio included	No audio included at platform level
Security features	Kensington Lock-ready
Power requirements	100 - 240 VAC, 50 - 60 Hz
Multimedia connections	Optional HP Flat Panel Speaker Bar: powered directly by the monitor or PC, the Speaker Bar attaches to the monitor's lower bezel to bring full audio support to select HP Flat Panel Monitors. Features include dual speakers with full sound range and external jack for headphones, part number EE418AA. For more information, refer to the product's Quick Specs. Optional HP Flat Panel Monitor Quick Release: an easy-to-use, VESA-compliant, flat panel monitor mounting solution that allows you to quickly and securely attach a flat panel monitor to a variety of stands, brackets, arms or wall mounts, part number EM870AA. For more information, refer to the product's Quick Specs.
Recommended resolution	Preset VESA Graphic Modes (non-interlaced): 1280 x 1024 @ 60 and 75 Hz, 1024 x 768 @ 60 and 75 Hz, 1152 x 870 @ 75 Hz (Mac), 1152 x 900 @ 66 Hz (Sun), 832 x 624 @ 75 Hz (Mac), 800 x 600 @ 60 and 75 Hz, 720 x 400 @ 70 Hz, 640 x 480 @ 60 and 75 Hz
Active display area (W x H)	409.8 x 256.7 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	50 W
Power consumption (off)	1 W
Power consumption (standby)	2 W
Power consumption (typical)	37 W
Operating altitude	0 - 3658 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-34 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	5 - 90 %
Package depth	174 mm
Package width	536 mm
Package height	423 mm
Package weight	6450 g
Sustainability certificates	EPEAT Silver, ENERGY STAR
Cables included	AC, VGA
Power cable length	1.9 m

Weight and Dimensions

Depth (with stand)	187 mm
Width (with stand)	446 mm
Height (with stand)	370 mm
Weight (with stand)	5100 g
Depth (without stand)	59 mm
Height (without stand)	301 mm
Weight (without stand)	4200 g
