HP LP3065 Specification

Panel Type 30.0-inch Wide Format Active Matrix TFT (thin film transistor)
Viewable Image Area
(diagonal)
29.77 in (75.623 cm)
Screen Opening (WxH) 25.3 x 15.8 in (64.3 x 40.3 cm)
Panel Type IPS
Aspect Ratio 16:10
Viewing Angle
(typical)
1
Up to 178° H/ 178° V (10:1 minimum contrast ratio)
Brightness (typical)
1
370 nits (cd/m
2
)
Contrast Ratio
(typical)
1
1000:1
Dynamic Contrast
Ratio (typical)
1
3000:1
Response Rate
(typical)
1
12 ms (5 ms average gray to gray)
Pixel Pitch 0.250 mm
Backlight Lamp Life
(to half brightness)
40K hours
Color Gamut 102% of NTSC
Bezel Width 24 mm (left and right)
User Controls Buttons and Switches Input select, brightness up, brightness down, power
User Controls Brightness, input selection
Signal Interface/
Performance
Horizontal Frequency 100 KHz
Vertical Frequency 60 Hz
Native Resolution 2560 x 1600 @ 60 Hz (native aspect ratio of 16:10)
2
Pixel Clock Speed 275 MHz
Anti-Glare Yes
Anti-Static Yes
Default Color
Temperature
6500 K
Video/Other Inputs Plug and Play Yes
Self Powered USB 2.0
Hub
One upstream, four downstream ports (located on side of monitor,
cable included)
Input Connectors Three dual-link DVI-D inputs with HDCP over digital DVI
2
Video Cable Two dual-link DVI cables
Video Cable Length 5.9 ft (1.8 m)
Power Input Power Auto-Ranging, 100 to 240 VAC; internal power supply, 50 Hz/60 Hz
Typical Power
Consumption
132 watts
Maximum < 176 watts
Power Saving < 2 watts
Power Cable Length 5.9 ft (1.8 m)
Mechanical Dimensions
(H x W x D)
Unpacked 19.3 to 23.2 x 27.2 x 9.5 in
(49.0 to 59.0 x 69.2 x 24.0 cm)
Unpacked w/o stand
(head only)
17.9 x 27.2 x 3.3 in
(45.5 x 69.2 x 8.4 cm)
QuickSpecs
HP LP3065 30-inch Widescreen LCD Monitor
Technical Specifications
DA - 12621 Worldwide QuickSpecs — Version 16 — 12/15/2008 Page 2

HP LP3065 Specifications

General

Pixel pitch	0.250 mm
Response time	6 ms
Display diagonal	30 \
Display resolution	2560 x 1600 pixels
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display scanning frequency	Horizontal frequency: 100 kHz, Vertical frequency: 60 Hz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	2560 x 1600 (WQXGA)
UNSPSC-code	43211902
On/off switch	Yes
Audio included	No audio includedNo audio included at platform level
Security features	Kensington Lock-ready
Weight (imperial)	Unpacked30.6 lb lbs
Power requirements	Auto-Sensing, 100 to 240 VAC, 50 +/-3 Hz to 60 +/-3 Hz)
Display resolution at frequency	2560 x 1600 @ 60 Hz (native)
Dimensions (W x D x H) (imperial)	27.2 x 3.3 x 17.9 \
Product dimensions (with stand, imperial)	27.2 x 9.5 x 23.2 \
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	5 - 85 %
Tilt angle range	-5 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (standby)	2 W
Power consumption (typical)	118 W
Certification	Australian ACA Approval, Canadian Requirements/CSA, CE Marking, China CCIB/CCEE Approval, CISPR Requirements, Eastern European Approvals, FCC Approval, German Ergonomic (TUV and GS Mark), ISO 9241-3, 7, 8 VDT Guidelines, ISO 13406-2 Pixel Defect Guidelines, Mexican NOM Approval, MIC Requirements (New Zealand), MPR-II Compliant, Nordic Approvals (Nemko, Fimko, Demko, Semko), S. Korean MIC Approval, Taiwan BSMI Approval, TCO 99 (emissions, ergonomics, environment), TUV-Ergo, UL Listed, VCCI Approvals, Microsoft Windows Certification (Microsoft Windows 98, Microsoft Windows 2000, and Microsoft Windows XP)
Product color	Black
Country of origin	China
I/O ports	One upstream, four downstream USB 2.0 Hub ports (cable included)
USB hub version	2.0
DVI-D ports quantity	3
DVI-I ports quantity	0
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4

Weight and Dimensions

Depth (with stand)	240 mm
Height (with stand)	590 mm
Weight (with stand)	13400 g
Depth (without stand)	84 mm
Width (without stand)	692 mm
Height (without stand)	455 mm
