2. Position the monitor head facedown and attach the stand to the back of the monitor head (1), and then

secure it with the thumbscrews (2).

Mounting the monitor head

To attach your monitor to a wall using a swing arm or other mounting xture, follow the steps in this section

to safely and securely connect your monitor.

IMPORTANT: This monitor supports the VESA industry-standard 100 mm mounting holes. To attach a third-

party mounting solution to the monitor head, use four 4 mm, 0.7 pitch, and 10 mm long screws. Longer

screws might damage the monitor. Be sure that the manufacturer’s mounting solution is compliant with the

VESA standard and is rated to support the weight of the monitor head. For best performance, use the power

and video cables provided with the monitor.

NOTE: This apparatus is intended to be supported by a UL-listed or CSA-listed wall-mount bracket.

Removing the monitor stand

If you decide to use a wall mount instead of the monitor stand that you attached, rst remove the stand.

IMPORTANT: Before you disassemble the monitor, be sure that the monitor is turned o and all cables are

disconnected.

IMPORTANT: To position and stabilize the monitor, HP recommends that two people perform these

procedures.

1. Disconnect and remove all cables from the monitor.

2. Position the monitor facedown on a at surface covered by protective sheet made of foam or a clean, dry

cloth.

3. Loosen the thumbscrews (1), and then swing the bottom of the stand up until the mounting plate clears

the recess in the monitor head (2).

Mounting the monitor head
