Fan
Description Spare part number
Fan 651606-001
The fan is located near the top of the computer. It is secured with three screws.
To remove the fan:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer on page 28).
2. Remove the small rear cover (see
Small Rear Cover on page 29).
3. Remove the stand (see
Stand on page 30).
4. Remove the right rear cover (see
Right Rear Cover on page 36).
5.
Remove the heat sink (see
Heat Sink (Thermal Module) on page 39).
6. Remove the rear cover (see
Rear Cover on page 47).
7. Remove the system board shield (see
System Board Shield on page 52).
8. Remove the three screws (1) that secure the fan to the computer.
9. Disconnect the fan cable (2) from the system board connector.
Fan
53
