EL-MF877-00 Page 2

Template Revision C

Last revalidation date 09-May-2018

HPI instructions for this template are available at EL-MF877-01

Item Description

Notes

Quantity of

items

included in

product

Components and parts containing toner and ink,

including liquids, semi-liquids (gel/paste) and toner

Include the cartridges, print heads, tubes, vent

chambers, and service stations.

Components and waste containing asbestos

Components, parts and materials containing refractory

ceramic fibers

Components, parts and materials containing

radioactive substances

2.0 Tools Required

List the type and size of the tools that would typically be used to disassemble the product to a point where components and

materials requiring selective treatment can be removed.

Tool Description

Tool Size (if

applicable)

Screw driver

Ph2/Ph00

Disassembly tool

Bolt sleeve

3.0 Product Disassembly Process

3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment

including the required steps to remove the external enclosure:

1. Lay the display on soft desk, separate Stand from Display Head.

2. Unscrew 4 VESA screws, unhook Bucket from Bezel.

3. Peel off Tapes and disconnect some terminals.

4. Take out Chassis and Panel.

5. Unfix Power Board and IF Board, take them out and disconnect some terminals.

3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items contained in the

product that require selective treatment (with descriptions and arrows identifying locations).

Questions and Answers:

Need help?

Do you have a question about the HP P204v and is the answer not in the manual?

HP P204v Specifications

General

3D	No
Panel type	TN
Color gamut	72 %
Pixel pitch	0.27 x 0.27 mm
Screen shape	Flat
Display diagonal	19.5 \
Display resolution	1600 x 900 pixels
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Viewing angle, vertical	50 °
Contrast ratio (typical)	600:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	90 °
Display brightness (typical)	200 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800, 1366 x 768, 1440 x 900 (WXGA+), 1600 x 900
HP segment	Business
NVIDIA G-SYNC	-
Depth	48.7 mm
Width	462.6 mm
Height	278.7 mm
Weight	2810 g
AC adapter included	Yes
Product color	Black
Country of origin	China
Sustainability certificates	EPEAT Gold, ENERGY STAR
HDMI version	1.4
DisplayPorts quantity	0
Tilt angle range	-5 - 25 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power consumption (max)	16 W
Power consumption (standby)	0.3 W
Power consumption (typical)	15 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, VGA
Package depth	136 mm
Package width	543 mm
Package height	349 mm
Package weight	4220 g
Harmonized System (HS) code	85285210
