Recognizing Preset Display Resolutions
The display resolutions listed below are the most commonly used modes and are set as factory
defaults. This monitor automatically recognizes these preset modes and they will appear properly
sized and centered on the screen.
NOTE: The preset modes can only be adjusted if the monitor is in PC mode. In Net mode, the
preset is locked at 1366 x 768 at 60Hz and cannot be adjusted.
1912nm and 1912nc Models (PC Mode)
Table 5-2 Factory Preset Modes
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 640 × 480 31.47 59.94
2 720 × 400 31.47 70.09
3 800 × 600 37.88 60.32
4 1024 × 768 48.36 60.00
5 1280 × 720 45.0 60.0
6 1280 × 960 60.0 60.0
7 1280 × 1024 63.98 60.02
8 1366 × 768 47.71 59.79
Table 5-3 High Definition Video Formats
Preset Timing Name Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 480p 720 × 480 31.469 60
2 576p 720 × 576 31.25 50
3 720p50 1280 × 720 37.5 50
4 720p60 1280 × 720 45 60
Entering User Modes
The video controller signal may occasionally call for a mode that is not preset if:
●
You are not using a standard graphics adapter.
● You are not using a preset mode.
It this occurs, you may need to readjust the parameters of the monitor screen by using the on-screen
display. Your changes can be made to any or all of these modes and saved in memory. The monitor
automatically stores the new setting, then recognizes the new mode just as it does a preset mode. In
addition to the factory preset modes, there are at least 10 user modes that can be entered and
stored.
28 Chapter 5 Technical Specifications ENWW
