HP Pro 3330 User Manual

Speaker
Description Spare part number
Speaker with rubber rivets 666885-001
The speaker is secured to the front of the chassis with three rubber rivets that are part of the speaker.
1. Prepare the computer for disassembly (
Preparation for Disassembly on page 42).
2. Remove the access panel (
Access Panel on page 43).
3. Remove the front bezel (
Front Bezel on page 45).
4. Lay the computer on its side so you can access both the inside and outside of the front of the
computer.
5. Disconnect the cable from the white system board connector labeled INT_SPKR.
6. From the front, squeeze the thicker part of the rubber rivets next to the chassis wall.
Figure 7-37 Speaker rubber rivets
Speaker 79

HP Pro 3330 Specifications

General

Chipset	Intel H61 Express
Power Supply	300W
Processor	Intel Core i3-2120
Memory	Up to 8 GB DDR3-1333 SDRAM
Storage	500GB 7200 rpm SATA
Graphics	Integrated Intel HD Graphics
Operating System	Windows 7 Professional
Optical Drive	DVD Writer
Audio	Integrated High Definition Audio
Network	Integrated 10/100/1000 Ethernet
Ports	6 USB 2.0, 1 VGA, 1 RJ-45
