HP ProLiant DL320 User Manual

Server operations 23
c. Lift the front of the assembly slightly and unseat the riser boards from
the PCI riser board connectors.
Installing PCI riser board assembly
CAUTION: To prevent damage to the server or expansion
boards, power down the server and remove all AC power cords before
removing or installing the PCI riser board assembly.
1. Align the PCI riser board assembly with the corresponding connectors on the
system board and install it into place.

HP ProLiant DL320 Specifications

General

Product Line	ProLiant
CPU Type	Intel Xeon
Storage	Up to 4 LFF (3.5") or 8 SFF (2.5") SAS/SATA/SSD drives (depending on model and configuration)
Network	Embedded 1GbE
Power Supply	Single or Redundant Power Supplies (depending on model and configuration)
Form Factor	1U
Server Type	Rack Server
