HP ProLiant ML30 Gen10 Plus User Manual

Installing a DIMMInstalling a DIMM
Before you perform this procedure, review:
DIMM population information
DIMM installation guidelines
ProcedureProcedure
1. Power down the server.
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Disconnect all peripheral cables from the server.
4. Do one of the following:
If the server is in tower mode, place the server on a flat, level surface with the access panel facing up.
If the server is in rack mode, remove the server from the rack .
5. Remove the access panel .
6. Install the DIMM:
a. Open the DIMM slot latches (callout 1).
b. Align the notch on the bottom edge of the DIMM with the keyed surface of the DIMM slot, and then fully press the DIMM into the
slot until the latches snap back into place (callout 2).
The DIMM slots are structured to ensure proper installation. If you try to insert a DIMM but it does not fit easily into the slot, you
might have positioned it incorrectly. Reverse the orientation of the DIMM and insert it again.
Installing a DIMM 138

HP ProLiant ML30 Gen10 Plus Specifications

General

Processor Sockets	1
Memory	Up to 128 GB DDR4 ECC UDIMM
Memory Slots	4
Form Factor	Tower
Processor	Intel Xeon E-2300 series
Storage	Up to 4 LFF or 8 SFF drives
RAID Support	HPE Smart Array S100i, S100i SR Gen10 SW RAID
Network	1 x 1GbE
Power Supply	350W
Chipset	Intel C252
Storage Controller	HPE Smart Array S100i, S100i SR Gen10 SW RAID
Maximum Internal Storage	Up to 64 TB
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Weight	Approx. 10.5 kg
