HP ProOne 600 G5 User Manual

Speakers
The speakers are located at the bottom of the computer behind the speaker cover. Two separate speakers are
each secured by two Phillips screws.
To remove the speakers:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 19).
2. Remove the stand (see Stand on page 19).
3. Remove the rear port cover (see Rear port cover on page 24).
4. Remove the system board (see System board on page 40).
5. Locate the speaker cover.
6. Rotate the top of the cover downward to disengage the snaps from the chassis, and then remove the
cover.
Speakers 43

HP ProOne 600 G5 Specifications

General

Processor	Intel Core i3/i5/i7/i9, Intel Pentium, Intel Celeron
RAM	Up to 64 GB DDR4
Storage	Up to 2TB HDD, up to 1TB SSD
Display	21.5" diagonal FHD (1920 x 1080) IPS anti-glare WLED-backlit
Graphics	Intel UHD Graphics 630
Operating System	Windows 10 Pro
Ports	USB 3.1 Gen 1, USB-C, HDMI, DisplayPort, RJ-45, audio jack
Network	Gigabit Ethernet
Chipset	Intel® Q370
Audio	Integrated stereo speakers
Networking	optional Wi-Fi 6, Bluetooth 5.0
Power Supply	up to 89% efficiency
