Selects the highlighted menu or screen item. If used from a top-level menu item, it displays
the sub-menu with no items highlighted; press OK a second time to return to the top-level
menu. When a sub-menu is displayed, OK selects the highlighted menu item. In a
configuration screen, the OK button toggles from navigation to editing a
selection. Navigate to an option you wish to change and press OK to edit it. Once the
item has been changed, press OK again to go back into navigation mode. The OK
button is also used for selecting highlighted choices such as <Save> or <Cancel>.
OK
Using the OCP
Each time the Tape Library is powered on or rebooted, or after five minutes of inactivity, a splash
screen is briefly displayed, after which the OCP menu is displayed, showing current system status
information.
You will be required to enter the administrator password for all functions that are password-protected.
Figure 82 OCP menu, showing initial system status information
.
The OCP menu includes a status message bar, menu bar, and display area. Initial system status
information includes basic Library, drive, and magazine status and information. All drives that have
been activated are included. If drives are subsequently removed or powered down, they will still be
listed on this screen until you restore defaults.
Status message bar
The highlighted line above Info, Configuration, Operations and Support is always visible. It shows
the time and overall status of the Library. Status definitions are listed in Table 28.
Table 28 Library status
DefinitionStatus
Library is ready for normal operationReady
Library is in a warning condition such as a drive needs cleaning (normal operation)Warning
Library is in an error condition (normal operation)Error
Library is running testsOffline
HP StorageWorks MSL2024, MSL4048, MSL8048, and MSL8096 Tape Libraries User and service
guide 133
