HP Stream 14 Product End-Of-Life Disassembly Instructions

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
refractory ceramic fibers
Components, parts and materials containing
radioactive substances
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Screw driver
#0
Description #2
Description #3
Description #4
Description #5
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Remove screw rubber F / R from D base
2. Remove rubber foot x 8screw rubber F / R from D base
3. Remove D base sub-Assy. from unit
4. Dis-connect battery pack connector from M/B.
5. Remove screw M2L2.5 x3 on battery pack.
6. Remove screw M2L6 x2 on battery pack.
7. Remove battery pack &Battery cable from unit.
8. Dis-connect speaker connector from M/B
9. Remove speaker from unit.
10. Dis-connect K/B membrane, TP FFC, power FFC ,DC cable connector from M/B
11. Dis-connect RTC battery connector from M/B
12. Dis-connect LCD cable connector from M/B
13. Dis-connect DC in cable connector from M/B
14. Dis-connect WLAN antenna cable from WLAN module
15. Remove screw M2L2.5 x 1 on WLAN module
16. Remove WLAN module from unit
17. Remove screw M2L2 x 3&M2X2.5 X2 on M/B
18. Remove M/B from unit
19. Remove screw M2L2 x 2 on thermal plate
20. Remove Thermal plate form MB.
21. Remove antenna cable & LCD cable from unit
22. Remove screw L2.5L5 x 4 on hinge L / R bracket
23. Remove LCD sub-Assy. from unit
24. Remove DC cable connector from TOP.
25. Remove power FFC from D/B Pow.
26. Remove screw M2L2.5 x 1 on D/B Pow.
27. Remove D/B Pow. from C top sub-Assy.
28. Remove TP FFC from TP module
29. Remove screw M2L2.5 x 3 on TP support bracket
30. Remove TP support bracket from C top sub-Assy.
31. Remove screw M2L2 x 3 on TP holder bracket
32. Remove TP holder bracket & TP module & TP mylar from C top sub-Assy.
33. Remove screw M2L2 x1 on Kb hook.
34. Remove LCD bezel from LCD sub-Assy.
35. Remove screw M2L2.5 x 4 on LCM ears
36. Remove LCM from LCD sub-Assy.
