HP Z210 Support Manual

Product Items/Features
(Blank box or unlisted means the component is NOT supported)
RH EL WS 4.8 or later
(x86 & EM64T)
RH EL DT 5.3 or later
(x86 & x86_64)
RH EL WS 6.0 or later
(x86 & x86_64)
SLED11 or later
(x86_64)
HP Workstation Base System
Base system includes: Chassis, System Board, USB, Power Supply, etc
••••
Localization Kit (See footnote 1)
HP Localization Ki
t
••••
Software
Remote Graphics Software
All Supported Processors
All Supported Processors (1 CPU configs) ••••
Hyperthreading
••••
Graphics Card (Video Card) (See footnote 2)
No Graphics Card
••••
NVIDIA Quadro NVS 295
••••
NVIDIA Quadro NVS 300
••••
NVIDIA Quadro NVS 450
••••
NVIDIA Quadro FX380
••••
NVIDIA Quadro 400
••••
NVIDIA Quadro FX580
••••
NVIDIA Quadro 600
••••
NVIDIA Quadro FX1800
••••
NVIDIA Quadro 2000
••••
NVIDIA Quadro FX3800
••••
NVIDIA Quadro 4000
••••
NVIDIA Quadro FX4800
••••
NVIDIA Quadro 5000
••••
ATI v2270 PCI-E - Single Card Supported
••••
ATI v3700 PCI-E - Single Card Supported
••••
ATI v5700 PCI-E - Single Card Supported
••••
ATI v7750 PCI-E - Single Card Supported
••••
ATI v3800 PCI-E - Single Card Supported
••••
ATI v4800 PCI-E - Single Card Supported
••••
ATI v5800 PCI-E - Single Card Supported
••••
System RAM
Minimum (GB)
1GB 1GB 1GB 1GB
Maximum (GB)
24GB 24GB 24GB 24GB
Hard Disks
All Supported SAS disk drives 4444
All Supported SSD disk drives ••••
All Supported SATA disk drives 4,5 4,5 4,5 4,5
All Supported USB Drive Keys ••••
Network Cards (no modem support)
Broadcom 5761 PCI-Express
••••
Intel Pro 1000 CT Gigabit PC
I
••••
Intel NC360T PCIe Dual Port Gigabit NI
C
••••
Onboard Components
Onboard LAN - Broadcom 5764 10/100/100
0
••••
Onboard Audi
o
••••
Onboard SATA RAI
D
4444
Add Ons
LSI 3041E SAS Card
4444
LSI 8888 ELP
4444
LSI 9212-4i
4444
LSI 9260-8i
4444
IEEE 1394A PCI Card
•
Creative Sound Blaster X-Fi
••
Removable CD/DVD Media
HP 16x DVD-ROM Drive
••••
HP 16x Super Multi DVD+RW
3333
HP BD-RE (writer)
••••
Input/Output Devices (no spaceball support)
HP 3-Button Mouse, PS/2
••••
HP Scroll Mouse, PS/2
••••
HP Optical Scroll Mouse, USB
••••
HP Standard Keyboard, USB/PS2
••••
TPM module/ Smart Card
22 in 1 Card Reader
•• •
HP Printers
6666
All supported monitors
••••
footnote 6 - For more info about Linux driver support for HP Printers please visit http://www.hplip.net.
footnote 7 - Hyperthreading is supported on platforms when the processor allows it. There are one or two low-end processors which do not support turbo mode or hyperthreading.
footnote 3 - Linux growisofs supports DVD+RW and Blu-ray media on Red Hat EL WS 4 or later, Red Hat EL 5 Desktop or later and SLED11 or later. For drives that have the Lightscribe functionality, pleas
e
visit www.lightscribe.com for software to enable the labeling feature.
Hardware Support Matrix for Current HP Linux Workstations
HP Z400 Workstation Linux Support
First time support begins with RHEL4.7 (x86 & x86_64), RHEL5.3 (x86 & x86_64), RHEL6.0 (x86 & x86_64) and SLED 11 (x86_64)
footnote 1 - Localization supported: (ABA US English, ABC French Canadian, ABD Germany, ABE Spain, ABF France, ABG Australia, ABU UK English, ABJ Japan, AB2 China (PRC), AB4 Singapore/
Malaysia, ABZ Italy, AB5 Hong Kong, ACF Japan-English, ACJ India-English, AB0 Taiwan, AK6 Europe A4, AC0 Belgium, ABS Sweden, ABB Int'l English).
footnote 2 - Get the latest drivers, "HP Installer Kit for Linux - HP Driver CD for Red Hat Enterprise Linux 4.7", "HP Installer Kit for Linux - HP Driver CD for Red Hat Enterprise Linux 5.3", and "HP Installer
Kit for Linux - HP Driver CD for SuSE Linux Enterpise Desktop 11" ISO images from http://www.hp.com/support/z400 (substitute correct platform name); Select "download drivers and software".
footnote 4 - Hardware RAID is supported using the LSI 3041E (RAID 0,1 SAS only), LSI 8888 ELP (RAID 0, 1, 5 SAS only), LSI 9212 (RAID 0,1 SAS only) and the LSI 9260-8i (RAID 0, 1, 5 SAS only).
SATA RAID is not supported.
footnote 5 - The Z400 can support up to 4 SATA drives. In order to support the third and fourth SATA drives, the customer needs the Optical Bay Conversion Kit for each drive.

HP Z210 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	6 MB
Processor cores	4
Processor model	E3-1225
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor codename	Sandy Bridge
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	31
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Graphics card	Quadro 600
Dimensions (WxDxH)	100 x 381 x 338 mm
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
Maximum internal memory	16384 MB
Graphics card manufacturer	Nvidia
Audio system	ALC261
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Memory layout (slots x size)	- GB
HDD speed	- RPM
RAID levels	0, 1
HDD capacity	500 GB
SSD capacity	160 GB
HDD interface	SATA II
SSD interface	SATA
Optical drive type	DVD-RW
Total HDDs capacity	1000 GB
Card reader integrated	-
Number of HDDs installed	2
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
USB 2.0 ports quantity	14
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Chassis type	SFF
Product color	Black
Country of origin	China
Compatible operating systems	Windows 7
Power supply	240 W
Certification	ENERGY STAR 5.0
Processor code	SR00G
Processor ARK ID	52270
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	381 mm
Width	100 mm
Height	338 mm
Weight	7600 g
