Designator Silk screen Component
P66 - P67 P66 - P67
SATA4 - SATA5
SATA Connectors
P70 P70 CPU0 FAN Primary CPU fan header
P93 P93 FRNTFAN Front fan header
P94 P94 IOH FAN IOH fan header
P124 P124 HLCK Side access panel solenoid lock header
XBT1 XBT1 BAT Battery holder
XMM1 - XMM6 4-DIMM: XMM1-XMM4, DIMM1-DIMM4
6-DIMM: XMM1-XMM6, DIMM1-DIMM6
Memory slots
XU1 XU1 CPU0 Primary CPU socket
200 Appendix B System board designators ENWW
