Installation guidelines

To avoid personal injury or product damage when installing your switch, read the following installation precautions and

guidelines.

Installation precautions

• Static electricity can severely damage the electronic components on the modules. When handling and installing the

modules in your switch, follow these procedures to avoid damage from static electricity:

• Handle the module by its bulkhead or edges. Avoid t

ouching the components, and the circuitry on the board.

• When installing the module, equalize any sta

tic charge difference between your body and the switch by wearing a

grounding wrist strap and attach it to the switch’s metal body, or by frequently touching the switch’s metal body.

• HP zl2 Modules have “low-force”, high-performa

nce connectors. High insertion forces are not necessary to install the

modules, and should not be used.

• Ensure you fully insert the modules. Th

at is, press the module into the slot until the bulkhead on the module is

contacting or is very close to contacting the front face of the switch chassis.

• For safe operation, proper switch cooling, and reduction of el

ectromagnetic emissions, ensure that a slot cover is

installed on any unused module slot. For safety, no more than one slot should be uncovered at a time when the switch

is powered on.

• Ensure you check the temperature

specifications for each module that will be installed into the chassis as different

modules may have different temperature requirements.

• For additional precautions, see the Inst

allation and Getting Started Guide for your module. For the latest version, visit

the HP Networking Web site at www.hp.com/networking/support.

For additional Safety and Regulatory information, see the HP 540

0R zl2 Quick Start Guide and Safety/Regulatory Information

document included with your module.

Interior Wiring

Warning

The information contained herein is subject to change without notice.

Printed in Singapore

June 2014

5998-5072
