HP ZR30w Technical Specifications

Performance
Vertical Frequency 60 Hz
Native Resolution 2560 x 1600 @ 60 Hz
Preset VESA Graphic
Modes (non-interlaced)
2560 x 1600 @ 60 Hz
Text Mode Not Supported
Maximum Pixel Clock
Speed
275 MHz
User Programmable
Modes
No
Anti-Glare Yes
Anti-Static Yes
Default Color
Temperature
6500 K
Video/Other Inputs Plug and Play Yes
Self Powered USB 2.0 Hub One upstream, four downstream ports (cable included)
Input Connectors 1 DisplayPort in, 1 Dual-Link DVI-D; HDCP support on DisplayPort and DVI
Input Impedance Not Applicable
Sync Input Separate synch
Video Cable (1) Dual-Link DVI-D to DVI-D, (1) DisplayPort
Video Cable Lengths 1,8 m (5.9 ft)
Power Input Power 100 - 240 VAC, 50 or 60 Hz
Typical Power
Consumption
130W
Maximum 185 W
Power Saving < 2 W
Power Cable Length 1,8 m (5.9 ft)
Mechanical Dimensions (H x W x D) Unpacked w/stand 48,9-58,9 x 69,4 x 27,6 cm
(19.3 - 23.3 x 27.3 x 10.9 in.)
Unpacked w/o stand (head
only)
45,4 x 69,4 x 8,7 cm
(17.9 x 27.3 x 3.4 in.)
Packaged 38,3 x 56,0 x 78,8 cm
(15.1 x 22.0 x 31.0 in.)
Weight Head Only 9.5 kg (20.9 lbs)
Unpacked 13 kg (28.6 lbs)
Packaged 17 kg (37.5 lbs)
Ergonomic Features 6-Way Comfort Adjust Easily adjust the display in height, tilt, and swivel for maximum comfort. Six
degrees of adjustment freedom including height up/down, tilt forward/back,
swivel left/right
HP Quick Release Ultra convenient set up. Easily mount and detach the display head from the
stand.
QuickSpecs
HP ZR30w 30-inch S-IPS LCD Monitor
Technical Specifications
DA - 13635 North America — Version 9 — January 29, 2013 Page 3

HP ZR30w Specifications

General

3D	No
Pixel pitch	0.2505 x 0.2505 mm
Display surface	Matt
Display diagonal	30 \
Display resolution	2560 x 1600 pixels
Viewable size diagonal	762 mm
Contrast ratio (dynamic)	3000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	370 cd/m²
Supported graphics resolutions	2560 x 1600 (WQXGA)
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Product color	Black
Country of origin	China
Market positioning	Business
HDCP	Yes
USB hub version	2.0
DVI-D ports quantity	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	5
LED indicators	Power
Tilt angle range	-5 - 35 °
Height adjustment	100 mm
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	185 W
Cables included	AC, DisplayPort, DVI, USB
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	276 mm
Height (with stand)	489 mm
Depth (without stand)	87 mm
Width (without stand)	694 mm
Height (without stand)	454 mm
Weight (without stand)	13000 g
