lineprofile-id 10 ont-srvprofile-id 10 descont alarm-profile 1 1 profile-id 1
ont alarm-profile 1 2 profile-id 1
ont port native-vlan 1 1 eth 1 vlan 10
ont port native-vlan 1 2 eth 1 vlan 10
quit
traffic table ip index 8 cir 4096 priority 1 priority-policy tag-In-Package
service-port 1 vlan 100 gpon 0/1/1 ont 1 gemport 1 multi-service user-vlan 10 rx-
cttr 8 tx-cttr 8
service-port 2 vlan 100 gpon 0/1/1 ont 2 gemport 1 multi-service user-vlan 10 rx-
cttr 8 tx-cttr 8
queue-scheduler wrr 10 10 20 20 40 0 0 0
cos-queue-map cos0 0 cos1 1 cos2 2 cos3 3 cos4 4 cos5 5 cos6 6 cos7 7
save
3.3.3 Configuring the GPON FTTH Layer 3 Internet Access Service
on the OLT CLI
The OLT is connected to the remote ONT through a GPON port to provide users with the high-
speed Internet access service.
Service Requirements
l Users' PCs are connected to the ONT using the LAN port. IP addresses of users' PCs are
allocated by the DHCP IP address pool on the ONT. After PPPoE auto dialup is performed
on the ONT, the ONT is connected to the upper-layer device in GPON mode to implement
high-speed Internet access service.
l The high-speed Internet access service is identified by two precisely-bound VLAN tags.
On the ONT, each user is allocated with a CVLAN; on the OLT, each slot is allocated with
an SVLAN.
l The high-speed Internet access service adopts a bandwidth-ensured mode with the
maximum bandwidth 100 Mbit/s as the DBA profile and performs the 4 Mbit/s rate
limitation on both the upstream and downstream directions.
Table 3-6 Data Plan
Item
Data
OLT Service VLAN ID: 100
Service VLAN type: Smart
Service VLAN attribute: stacking
Upstream port: 0/19/0
ONT ONT IDs: 1 and 2
ID of the port on the ONT that is connected to the PC: 1
Type of the port on the ONT that is connected to the PC:
ETH
VLAN ID of the port on the ONT that is connected to the
PC: 10
User name for PPPoE dialup: iadtest@pppoe; password:
iadtest
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
139
