No.
LED Status
Description
PON LOS
6
Blinks quickly
(twice per
second)
Blinks slowly
(once two
seconds)
The Rx optical power of the ONT
does not within the range (–27
dBm to –8 dBm) of the Rx
sensitivity.
7
Blinks slowly
(once two
seconds)
Blinks slowly
(once two
seconds)
The hardware is faulty.
Device parameters
The device parameters include the ONT's size, weight, operating environment, and power
parameters and equipment power consumption.
Table 1-23 HG8240F device parameters
Parameter Specifications
Dimensions (length x width x height) 176 mm x 138.5 mm x 28 mm
Weight about 235 g
Working environment Operating temperature: 0ºC to +40ºC
Environment humidity: 5% RH to 95% RH
(non-condensing)
Pressure environment: 86 kPa to 106 kPa
Altitude: 2000 m
Power specifications Power adapter input: 100 V AC to 240 V AC,
50 Hz to 60 Hz
System power supply: 11 V DC to 14 V DC,
1A
Power consumption
l Static power consumption: 5.5 W
l Maximum power consumption: 7.5 W
EchoLife HG8242H/HG8240H/HG8240F/HG8110H GPON
Terminal
Product Description 1 Introduction
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
21
