Huawei FusionServer Pro 1288H V5 User Manual

Callout No. Description
4 Year and month (two characters).
● The rst character indicates the year.
– Digits 1 to 9 indicate years 2001 to 2009, respectively.
– Letters A to H indicate years 2010 to 2017, respectively.
– Letters J to N indicate years 2018 to 2022, respectively.
– Letters P to Y indicate years 2023 to 2032, respectively.
NOTE
The years from 2010 are represented by uppercase letters excluding
I, O, and Z because the three letters are similar to digits 1, 0, and 2.
● The second character indicates the month.
– Digits 1 to 9 indicate January to September, respectively.
– Letters A to C indicate October to December, respectively.
5 Sequence number (six characters).
6 RoHS compliance (one character). Y indicates RoHS compliant.
7 Internal model, that is, product name.
A.2 Operating Temperature Limitations
Table A-2 Operating temperature limitations
Conguratio
n
Max. 35°C (95°F) Max. 40°C (104°F) Max. 45°C (113°F)
4 x 3.5" drive
conguration
● All options
supported
Options not
supported:
● Platinum
8180/8168/8280
/8280L/8280M/
8268 and Gold
6154/6254
processors
● PCIe SSD cards
● NVMe drives
● Passive GPU
cards
Options supported:
● Platinum 8153,
Gold
6152/6140/6126
/5118/5215,
Silver
4216/4215/4214
, and other
processors lower
than 105 W
Options not
supported:
● PCIe SSD cards
● NVMe drives
● Passive GPU
cards
● IB and OPA
cards
FusionServer Pro 1288H V5 Server
User Guide A Appendix
Issue 13 (2020-06-05) Copyright © Huawei Technologies Co., Ltd. 135

Huawei FusionServer Pro 1288H V5 Specifications

General

Processor	Intel Xeon Scalable processors
Memory	Up to 3 TB
Memory Slots	24 DDR4 DIMM slots
Storage	Supports up to 10 x 2.5-inch SAS/SATA/SSD drives or 4 x 3.5-inch SAS/SATA drives
RAID Support	RAID 0, 1, 10, 5, 50, 6, 60
Network	2 x GE + 2 x 10GE ports
Power Supply	1+1 redundant, hot-swappable PSUs
Form Factor	1U rack
