Huawei HG530 User Manual

25
Item Specification
Entire-device power
consumption
< 6 W
Ambient temperature
for operation
0°C to 40°C (32°F to 104°F)
Relative humidity for
operation
5% to 95%, non-condensing
Dimensions (L × W ×
H)
156.4 mm × 52 mm × 124.3 mm
Weight About 245 g
ADSL
standards
z G.992.1 (G.dmt) Annex A
z G.994.1 (G.hs)
z ANSI T1.413 Issue 2
ADSL2
standards
z G.992.3 (G.dmt.bis) Annex A
z G.992.3 (G.dmt.bis) Annex L
ADSL2+
standard
G.992.5 (G.dmt.bitplus) Annex A
Standards
WLAN
standards
802.11b, 802.11g and 802.11n
(2.4 GHz)
G.dmt
T1.413
z Maximum downlink rate: 8
Mbit/s
z Maximum uplink rate: 896 kbit/s
DSL transmission
rates
G.992.5
(ADSL2+)
z Maximum downlink rate: 24
Mbit/s
z Maximum uplink rate: 1024
kbit/s

Huawei HG530 Specifications

General

Wireless Standard	802.11b/g
Frequency Band	2.4 GHz
ADSL Standard	ADSL2+
Security	WEP, WPA, WPA2
ADSL Standards	G.992.1 (G.dmt), G.992.2 (G.lite), G.992.3 (ADSL2), G.992.5 (ADSL2+)
Ethernet Ports	4 x 10/100 Mbps
