No. Description
1 Indicates the ESN ID.
2 Indicates the material identification code
(eight characters).
3 Indicates the vendor code (two characters).
4 Indicates the year and month (two
characters).
5 Indicates the serial number (six characters).
2.3 Ports
Table 2-3 and Table 2-4 describe the external ports on the RH2288 V3.
Table 2-3 Ports on the front panel
Port
Type Quantity Description
Video
graphics
array
(VGA)
port
DB15 1 The VGA port is used to connect a terminal,
such as a monitor or KVM.
USB port USB 2.0 2 The USB ports are connected to USB devices.
NOTE
Before connecting to an external USB device, check
that the USB device operates properly. A server may
fail if it is connected to an abnormal USB device.
Table 2-4 Ports on the rear panel
Port
Type Quantity Description
VGA port DB15 1 The VGA port is used to connect a terminal,
such as a monitor or KVM.
USB port USB 3.0 2 The USB ports are connected to USB devices.
NOTE
Before connecting to an external USB device, check
that the USB device operates properly. A server may
fail if it is connected to an abnormal USB device.
USB 3.0 is disabled by default. You can enable it on
the BIOS as required.
RH2288 V3 Server
User Guide
2 Overview
Issue 32 (2019-03-28) Copyright © Huawei Technologies Co., Ltd. 17
