6.6 AC Power Cable
Appearance and Structure
Figure 6-18 shows the appearance of an AC power cable.
Figure 6-18 AC power cable
NOTE
The AC power cables used in different countries and regions may have different specifications. Figure
6-18 shows the AC power cable complying with China's national standard. The power cable and plug
delivered with the chassis can only be used on this chassis, and cannot be used on other devices.
Connection
An AC power cable connects to the following:
l An AC power input port on the device
l The mains supply
6.7 Console Cable
Appearance and Structure
Figure 6-19 and Figure 6-20 show the appearance and structure of a console cable.
S6700 Series Ethernet Switches
Hardware Description
6 Cables
Issue 12 (2015-07-31) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
79
