No. Indicator Identifier Status Description
has an
arrowhead
pointing to the
CON port.
Green The Mini USB port is
not in use. This
indicator is steady
green unless the Mini
USB port is accessed.
Table 2-18 Description of service interface indicators in different modes
Display Mode Status Description
STAT Off The interface is not connected or
has been shut down.
Green The interface is connected.
Blinking green The interface is sending or
receiving data.
Speed Off The interface is not connected or
has been shut down.
Green 10M/100M/1000M interface: The
interface is operating at 10/100
Mbit/s.
1000M/10G interface: The
interface is operating at 1000
Mbit/s.
Blinking green
10M/100M/1000M interface: The
interface is operating at 1000
Mbit/s.
1000M/10G interface: The
interface is operating at 10 Gbit/s.
PoE Off The interface does not provide
PoE power.
Green The interface is providing PoE
power.
Orange The PoE function on the interface
is disabled.
Blinking orange A PoE fault occurs. For example,
an incompatible cable or PD is
connected to the interface or the
PoE power supply unit is faulty.
S3700&S5700&S6700 Series Ethernet Switches
Quick Start 2 Product Hardware Introduction
Issue 02 (2012-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
41
