Table 9-16 DIP switches of SW2
DIP
Switch
Indication
1, 2, 3 Set the subnode addresses corresponding to the data configurations.
l ON: The address bit is 0.
l OFF: The address bit is 1.
The default value of the address bit is 1.
4 ON This is a default setting. The fan tray communicates with the control
board at a baud rate of 19200 bit/s.
OFF The fan tray communicates with the control board at a baud rate of
96000 bit/s.
Table 9-17 describes the settings of SW2-1, SW2-2, and SW2-3.
Table 9-17 Settings of SW2-1, SW2-2, and SW2-3
SW2-3 SW2-2 SW2-1 Address Bit Value
ON ON ON 0
ON ON OFF 1
ON OFF ON 2
ON OFF OFF 3
OFF ON ON 4
OFF ON OFF 5
OFF OFF ON 6
OFF OFF OFF 7
9.8 LED
The LED on the front panel of the fan tray indicates the running status of the fans. This topic
describes the status and meanings of the LED.
The LED is on the right of the fan tray. Table 9-18 describes the LED of the fan tray.
Table 9-18 LED of the fan tray
LED
Status Description
Green: on for 1s and off for 1s
repeatedly
The fan tray works in the normal state.
UA5000 Universal Access Unit
Environment Monitoring 9 Fan Tray Monitoring Solution
Issue 01 (2012-08-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
160
