Huawei UPS2000-A-1KTTL Quick Guide

Name: Huawei UPS2000-A-1KTTL
Brand: Huawei
Rating: 4 (1 reviews)

13 pages

To Next Page

To Previous Page

UPS Model

Represented By Weight Dimensions (H x W x D) Remarks

UPS2000-A-

1KTTS/UPS2000-A-

1KTTS-01

1 K

-standard model-

tower mounted

-IEC

9.4 kg 220 mm x 145 mm x 282

• With the

suffix 01:

Optional

cards are

not

supported.

• Without

the suffix

01:

Optional

cards are

supported.

UPS2000-A-

1KTTL/UPS2000-A-

1KTTL-01

1 K

long backup time

model

-tower

mounted

-IEC

4.6 kg 220 mm x 145 mm x 282

UPS2000-A-

2KTTS/UPS2000-A-

2KTTS-01

2 K

-standard model-

tower mounted

-IEC

17.5 kg 220 mm x 145 mm x 397

UPS2000-A-

2KTTL/UPS2000-A-

2KTTL-01

2 K

long backup time

model

-tower

mounted

-IEC

7.3 kg 220 mm x 145 mm x 397

UPS2000-A-

3KTTS/UPS2000-A-

3KTTS-01

3 K

-standard model-

tower mounted

-IEC

27.0 kg 318 mm x 190 mm x 421

UPS2000-A-

3KTTL/UPS2000-A-

3KTTL-01

3 K

long backup time

model

-tower

mounted

-IEC

8.0 kg 220 mm x 145 mm x 397

Introduction

(1) Mains

input socket (1 kVA/2 kVA: C14; 3 kVA: C20)

(2) Input

circuit breaker

(3) Universal

serial bus (USB) port (security protection

mechanism supported)

(4) RS232

port

(5)

Optional card slot

(6) External battery connector (only for

long backup time models)

(7) Output

socket (C13)

(8)

Output socket (C19)
