Husqvarna 128LD User Manual

English---14
115275126 Rev. 1 9/15/09
ASSEMBLY
Fitting the trimmer guard and
trimmer head (Model 128CD)
S Fit t he correct trimm er guard (A) for use
with the trimmer head. Hook the trimmer
guard/combination guard onto the fitting on
the shaft and secure with the wing nut (B).
A
C
B
S Fit the dust cup (C) on the shaft. The nut
must be completely covered by the dust
cup.
S Hold the dust cup with a wrench to pre-
vent the shaft from rotating.
S Screw the trimmer head (D) onto the
shaft.
S To dismantle, follow the instructions in
the reverse order.
D

Husqvarna 128LD Specifications

General

Engine Type	2-stroke
Maximum Power Speed	8000 rpm
Shaft Type	Straight
Cylinder Displacement	28 cm³
Power Output	0.8 kW
Fuel Tank Volume	0.4 liters
Cutting Width	17 inches
Starter System	Recoil
