18 – English
Driving
Remove the cables in the reverse order
• The BLACK cable is removed from the chassis and then
the fully charged battery.
• Finally the RED cable from both batteries.
Driving the Rider
1 Release the parking brake by first pressing down the
parking brake pedal and then releasing it.
2 Carefully press down one of the pedals until the required
speed is obtained. Pedal (1) is used to drive forwards, and
pedal (2) to drive backwards.
3 Press in the lock button on the mechanical lifting lever and
lower the cutting unit.
If the cutting unit does not lower completely, or if the
blades do not rotate, lower the cutting unit completely
using the hydraulic lifting lever. In order to ensure that the
hydraulic cylinder is in the outer position, hold the lever in
the forward position for a half to one second.
4 Select the required cutting height (1-7) with the cutting
height lever.
It is important that the air pressure in both front wheels is
equal, 60 kPa / 0,6 bar / 8.5 PSI, to produce an even
cutting height.
Braking
Release the drive pedals. The machine slows and is stopped
by the drive system. Do not use the parking brake as the drive
brake.
Quicker braking is possible if you press down the drive pedal
for the opposite direction.
Stop the engine
Preferably allow the engine to idle for a minute to obtain
normal working temperature before stopping it if it has been
working hard. Avoid idling the engine for long periods, as
there is a risk of carbon build-up on the spark plugs.
1 Lift the cutting unit with the hydraulic lifting lever.
The unit can then be secured in the raised position if
necessary by moving the mechanical lifting lever
backwards to the lock position.
If the cutting unit is left in the lower position, the start lock
circuit will prevent engine starts.
2
1
IMPORTANT INFORMATION
The life span of the drive belts is increased significantly if
the engine runs at a low speed when the blades are
engaged. Therefore apply full throttle first when the cutting
unit has been moved to the mowing position.
