108548_0711 6-5
Mower Deck Assy
NOTES:
ITEM
NO.
SERVICE
PART NO.
QTY. DESCRIPTION
1 51043-151-107 1 HOUSING MOWER DECK
2 36068-204 1 GUARD
3 51090-117-09 2 PROTECTOR
4 342L-0616 5 FLANGE BOLT
5 512L-0600 4 HEX NUT
6 36065-180 1 COVER
7 342L-0612 12 FLANGE TAPPING BOLT
8 11006-155 1 STAY C.P.
9 11113-407 1 STAY
10 11113-292 1 STAY
11 36068-196-49 1 GUARD REAR DOOR
12 36080-149 1 RUBBER SHEET
13 64014-324 1 SHAFT
14 68013-336 1 SPRING
15 71082-111 1 FAN ASSY (INCLUDES ITEMS 16–19)
16 51125-103 1 FAN
17 11102-151 1 HOLDER
18 31062-169 4 PRE-COAT LOCK BOLT
19 579L-0600 4 FLANGE BOLT
20 61024-208 1 SPACER
21 91014-189 1 BLADE STD M-1
22 31057-197 2 HEX BOLT
23 31057-243 4 HEX BOLT
24 61024-142 3 SPACER
25 71067-106 1 BRAKE ASSY
26 91097-101 1 UNIVERSAL JOINT
27 812V-2000 1 C-SNAP RING FOR SHAFT
28 717B-0418 1 PARALLEL PIN
29 64014-339 1 SHAFT
30 91049-129 1 CONNECTOR
31 68036-280 2 WASHER
32 816V-0800 1 E-SNAP RING
33 36065-438 1 COVER
34 51116-149 1 LEFT HANDLE BRACKET
35 51116-167 1 RIGHT HANDLE BRACKET
36 31057-255 4 HEX BOLT
37 512L-0800 4 HEX NUT
38 11113-429 1 RS STAY
39 11113-428 1 LS STAY
40 31057-181 2 HEX BOLT
41 11113-415 2 STAY
42 71008-431 1 GEAR CASE ASSY
43 711V-0522 2 SPRING PIN
44 733L-1000 1 SNAP PIN
45 94401-16150 1 WOODRUFF KEY
To Next Page
