Icom IC-M200 User Manual

19
10
SPECIFICATIONS AND OPTIONS
19
■ Specications
General
• Frequency coverage:
Transmit 156.025~162.000 MHz
Receive 156.025~162.025 MHz
• Type of emission : FM (16K0G3E)
• Antenna impedance : 50 Ω nominal
• Operating temperature range:
–20°C to +60°C
• Power supply voltage (negative ground):
13.8 V DC
• Current drain (at 13.8 V):
TX (at 25 W) 5.5 A maximum
Maximum audio 1.5 A maximum
• Dimensions: 153(W) × 67(H) × 133(D) mm
• Weight (approximately): 790 g
Transmitter
• Rated output power: 25 W (High) and 1 W (Low)
• Modulation: Variable reactance frequency
modulation
• Maximum frequency deviation:
±5.0 kHz
• Frequency tolerance: ±5.0 ppm
• Spurious emissions: Less than –70 dBc (High)
Less than –56 dBc (Low)
• Adjacent channel power: More than 70 dB
• Audio harmonic distortion (at 60% deviation):
Less than 10%
• Residual modulation: More than 40 dB
■ Options
Receiver
• Intermediate frequencies: 1st 21.7 MHz, 2nd 450 kHz
• Sensitivity (12 dB SINAD) : –121 dBm typical
• Squelch sensitivity: Less than –117 dBm
• Audio power output (at 10% distortion into 4 Ω):
4.5 W typical
• Adjacent channel selectivity: More than 70 dB
• Spurious response: More than 70 dB
• Intermodulation: More than 70 dB
• Hum and noise: More than 40 dB
• MB-69 flush mount kit
• MB-92 dust cover
Approved Icom optional equipment is designed for optimal
performance when used with an Icom transceiver.
Icom is not responsible for the destruction or damage to the Icom
transceiver, if the malfunction is because of:
• Force majeure, including, but not limited to, res, earthquakes,
storms, oods, lightning, other natural disasters, disturbances,
riots, war, or radioactive contamination.
• The use of Icom transceivers with any equipment that is not
manufactured or approved by Icom.

Icom IC-M200 Specifications

General

Purpose	-
Maximum range	- m
Operating frequency	156.025 - 162.025 MHz
Display type	LCD
Product color	Black
International Protection (IP) code	IPX7
Operating temperature (T-T)	-20 - 60 °C

Weight and Dimensions

Depth	67 mm
Width	153 mm
Height	133 mm
Weight	790 g
