Icom IC-M506 Service Manual

6-2
[FRONT UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
MC1 0800014230 HM-205B [#01] 1
(Optional) HM-205B [#04] 1
(Optional) HM-205B [#05] 1
(Optional) HM-205B [#06] 1
(Optional) HM-205B [#07] 1
(Optional) HM-205B [#09] 1
(Optional) HM-205B [#10] 1
0800014230 HM-205B [#11] 1
(Optional) HM-205B [#14] 1
(Optional) HM-205B [#15] 1
(Optional) HM-205B [#16] 1
(Optional) HM-205B [#17] 1
(Optional) HM-205B [#19] 1
(Optional) HM-205B [#20] 1
0800014230 HM-205B [#21] 1
(Optional) HM-205B [#24] 1
(Optional) HM-205B [#25] 1
(Optional) HM-205B [#26] 1
(Optional) HM-205B [#27] 1
(Optional) HM-205B [#29] 1
(Optional) HM-205B [#30] 1
SP1 2510001800 045P08010 1
W1** 9035700010 22/00/030/W02/W02 1
MP1 8210029830 3570 FRONT PANEL ASSEMBLY 1
MP4 8930089030 3570 SP HOLDER 1
MP5 8310084000 3570 D-COVER 1
MP6 8930088990 3570 SHAFT 1
MP7 8930089100 3570 SPRING 1
MP8 8930088960 3570 6-KEY (SC) 1
MP9 8930088970 3570 7-KEY (SC) 1
MP10 8930051970 2345 A-BUSH PLATE Y514 1
MP11 8930089610 3570 MIC CAP [#31] 1
8930089610 3570 MIC CAP [#34] 1
8930089610 3570 MIC CAP [#35] 1
8930089610 3570 MIC CAP [#36] 1
8930089610 3570 MIC CAP [#37] 1
8930089610 3570 MIC CAP [#39] 1
8930089610 3570 MIC CAP [#41] 1
8930089610 3570 MIC CAP [#41] 1
8930089610 3570 MIC CAP [#44] 1
8930089610 3570 MIC CAP [#45] 1
8930089610 3570 MIC CAP [#46] 1
8930089610 3570 MIC CAP [#47] 1
8930089610 3570 MIC CAP [#49] 1
8930089610 3570 MIC CAP [#50] 1
MP12 8610014660 KNOB N-420 1
MP13 8610014650 KNOB N-419 2
MP14 8930069020 O-RING (BG) 1
MP15 8930052280 O-RING (AC) (TOP) 2
MP16 8930055841 2490 EARTH SPRING-1 1
MP21 8810008661 PHBT M3 X 8 NI-ZC3 9
MP22 8810008661 PHBT M3 X 8 NI-ZC3 3
[LOGIC UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1* 6510022472 40FLT-SM2-TB (LF) (SN) (M) 1
J2* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J3* 6510030260 BM04B-PASS-TF (LF) (SN) 1
J4* 6510018921 B8B-PH-SM4-TB (LF) (SN) 1
J8* 6510022022 14FLT-SM2-TB (LF) (SN) (M) 1
J9* 6510028221 AYF532265T 1
J10* 6510019421 B8B-ZR-SM4-TF (LF) (SN) 1
J11* 6510027570 B7B-ZR-SM4-TF (LF) (SN) 1
DS1 5030003860 888BK01012 <SKD> 1
[DIAL UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1* 6510030480 IMSA-9210B-1-04ZA311-PT1 1
S1* 2250000730 TP90N245AE20PY-14.5F-3338 1
[VOL UNIT]
[SQL UNIT]
[CONNECT UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
REF ORDER
DESCRIPTION QTY.
NO. NO.
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1* 6510030470 IMSA-9210B-1-03ZA311-PT1 1
J1* 6510030470 IMSA-9210B-1-03ZA311-PT1 1
J1* 6510030290 ICOM-CCBPM08MCC <ODS> 1
J2* 6510025142 10FLT-SM2-TB (LF) (SN) (M) 1
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
