CONNECTIONS AND MAINTENANCE
12
■ Supplied accessories
Mounting bracket
For mounting bracket
Flat washers (M5)
Spring washers (M5)
DC power cable
Microphone hanger
and screws (3 × 16 mm)
Screws
(5 × 20 mm)
Knob bolts
Microphone Warning sticker
(For only the USA version)
NOTE:
depending on the transceiver version.
■ Fuse replacement
One fuse is installed in the supplied DC power cable. If the fuse blows or the transceiver
stops functioning, track down the source of the problem, repair it, and replace the
damaged fuse with a new one of the proper rating.
Fuse Coding explanation
Fuse Coding: F 250 V 10 A
Fuse Voltage Rating: 250 Volts
Fuse Current Rating: 10 Amperes
