SECTION 1 SPECIFICATIONS
1 - 1
‘‘
GENERAL
• Frequency coverage :
*Specifications Guaranteed: 144–148 MHz only
• Type of emission : F2D/ F3E
• Frequency stability : ± 10 ppm
(–10˚C to +60˚C; +14˚F to +140˚F)
• Tuning steps : 5, 10, 12.5, 15, 20, 25, 30 or 50 kHz
• Antnna connector : BNC (50 Ω)
• Power supply requirement : 7.2 V DC (Operable voltage range: 6.0 to 10.3 V)
(negative ground)
• Number of memory channel : 100 channels
• Call channel : 1 channel
• Scanning mode : Program, Memory, Skip, Priority or Tone
• Current drain (approx.) : Transmit at High (5.5 W) 2.0 A
at Low (0.5 W) 0.7 A
Receive Max. audio 250 mA
stand-by 70 mA
power saved 20 mA
• Usable temperature range : –10˚C to +60˚C; +14˚F to +140˚F
• Dimensions (projections not included) : 54(W)
× 132(H) × 35(D) mm; 2
1
⁄8(W) × 5
3
⁄16(H) × 1
3
⁄8(D) in.
• Weight (with ant., BP-222) : 350 g; 12.3 oz.
‘‘
TRANSMITTER
• RF output power (at 7.2 V DC) : 5.5 W / 0.5 W (High / Low)
(with supplied battery pack)
• Modulation system : Variable reactance frequency modulation
• Maximum frequency deviation : ±5.0 kHz
• Spurious emissions : Less than –60 dB
• Ext. microphone connector : 3-conductor 2.5(d) mm (
1
⁄10”)/2.2 kΩ
‘‘
RECEIVER
• Receive system : Double conversion superheterodyne system
• Intermediate frequencies : 1st 21.7 MHz
2nd 450 kHz
• Sensitivity : 0.16 µV at 12 dB SINAD (typical)
• Squelch sensitivity : 0.1 µV at threshold (typical)
• Adjacent channel selectivity : 65 dB (typical)
• Spurious response rejection : 75 dB (typical)
• Intermodulation rejection ratio : 65 dB (typical)
• Audio output power (at 7.2 V DC) : More than 300 mW at 10% distortion with an 8 Ω load
• Ext. speaker connector : 3-conductor 3.5(d) mm (
1
⁄8”)/8 Ω
All stated specifications are subject to change without notice or obligation.
Receive
136.000–174.000 MHz*
Transmit
144.000–148.000 MHz
136.000–174.000 MHz*
Version
[USA]
[GEN]
