Icom ID-800H User Manual

■ Programming memory channels
X
QUICK REFERENCE GUIDE
Quick reference guide
The ID-800H has a total of 512 memory channels (including
10 scan edges and 2 call channels) for storing often used op-
erating frequency, repeater settings, etc.
1. Setting a frequency
In VFO mode, set the desired operating frequency with re-
peater, tone and tuning steps, etc.
➥ Push [V/MHz•SCAN] to select VFO.
➥
Rotate [DIAL] to set the desired frequency.
• Set other data, such as repeater tone, duplex information, tuning
step, if desired.
2. Selecting a memory channel
Push [S.MW•MW], then rotate [DIAL] to select the desired
memory channel.
•“!” indicator and memory channel number blink.
3. Writing a memory channel
Push and hold [S.MW•MW] for 1 sec. to program.
• 3 beeps sound
• Return to VFO mode automatically after the program.
• Memory channel number automatically increases when continuing
to push [S.MW•MW] after programming.
Using the HM-133
q In VFO mode, set the desired operating frequency, includ-
ing offset direction, tone settings, etc.
➥ Push [VFO/LOCK] to select VFO.
➥ Push [
ENT C(T-OFF)] first, then enter the desired oper-
ating frequency via the keypad.
• Set other data, such as repeater tone, duplex information,
tuning step, if necessary.
w Push [FUNC] then [ CLR A(MW)].
•“!” indicator and memory channel number blink.
e Push [
YY
]/[
ZZ
] to select the desired memory channel.
r Push [FUNC] then push and hold [
CLR A(MW)] for 1 sec.
to program.
• 3 beeps sound
• Memory channel number automatically increases when continu-
ing to push [ CLR A(MW)] after programming.
Push ,
then
[S.MW•MW]
ID-800H_1.qxd 2007.06.14 3:09 PM Page X
