Icom ID-800H User Manual

28
5
MEMORY OPERATION
4
5
■ General description
The transceiver has 512 memory channels including 10 scan
edge memory channels (5 pairs), and 2 call channels. Each of
these channels can be individually programmed with operat-
ing frequency
(pgs. 11, 12), duplex direction (pgs. 21, 22) and
offset
(p. 26), subaudible tone encoder or tone squelch and its
tone frequency
(pgs. 21–24, 55, 56), skip information (p. 47) and
call sign memory number
(station and repeater; pgs. 61–64).
In addition, a total of 10 memory banks, A to J, are available
for usage by group, etc.
■ Memory channel selection
D Using the tuning dial
q Push [M/CALL•PRIO] several times to select memory
mode.
•“!” indicator appears
w Rotate [DIAL] to select the desired memory channel.
• Programmed memory channels only can be selected.
D Using the [
YY
]/[
ZZ
] keys
z Push [MR/CALL] to select memory mode.
x Push [
YY
] or [
ZZ
] to select and set the desired
memory channel.
• Pushing and holding [
YY
]/[
ZZ
] for 1 sec. activates a
scan.
• If scan is activated, push [
YY
]/[
ZZ
] again or push
[ CLR A(MW)] to stop it.
D Using the keypad
z Push [MR/CALL] to select memory mode.
x Push [
ENT C(T-OFF)] to activate the keypad
for numeral input.
c Push 3 appropriate digit keys to input a chan-
nel number.
• Blank channel can be selected.
• Push only 1 appropriate digit key, [ MONI
1(BANK)], [ SCAN 2(T-SCAN)], [ PRIO 3(PTT-M)],
[ HIGH 4(DTCS)] or [ MID 5(DTCS
SS
)] then push
[
MM
(TONE-1)] or [ SQL
ZZ
#(16KEY-L)] to select scan
edge channels. “
MM
” and “#” can be used for “A”
and “B” respectively.
MR/CALL
MR/CALL
Y/Z
[M/CALL•PRIO] “!” appears
ID-800H_1.qxd 2007.06.14 3:09 PM Page 28
