Classic SE FF - Installation & Servicing
INSTALLATION
The boiler is supplied fully assembled in Pack A, together with
a standard flue assembly for lengths up to 600mm (23
1/2"),
rear or side flue outlet, in Pack B.
Unpack and check the contents.
Pack B Contents
z Duct cutting support, 2 off
(cardboard )
z Terminal wall plate, 1 off.
z Terminal grille assy., 1 off.
z Polyurethane foam seal 400 lg., 1 off.
z No. 8 x 8 lg. Pozi pan hd. screws, 3 off.
8
UNPACKING
Pack A Contents
z The complete boiler
z Installation & Servicing/Users Instructions
z Hardware Pack (listed below)
z Wall mounting template
z Wall mounting plate
z Side outlet terminal mounting plate
z Flue extension tube - 1 off
z Boiler sealing ring - 1 off
Hardware Pack Contents
z 50mm x No. 14 wood screw, 4 off
z 50mm x No. 10 wood screw, 8 off
z Wall plug, 12 off
z M8 washer, 1 off
z 22mm x 28mm copper reducing socket
(SE21 FF, SE24 FF and SE30 FF ONLY), 2
off
z M5 wing nut, 3 off
z Sealing plate, 1 off
z M8 x 12 Hx. Hd. screw, 1 off
INSTALLATION
200544-5.pmd 20/02/2008, 13:2614
To Next Page
