1.3.7 Motor Torque/Speed Characteristics
MS1H1 (low inertia, small capacity)
Continuous
working area
Short time
working area
A
B
2,000
3,000
4,000
5,000
6,000
Speed (RPM)
1,000
0
0.45
Torque (N·m)
0.3
0.15
0.6
MS1H1-05B30CB
A B
0
2,000
3,000
4,000
5,000
6,000
Speed (RPM)
1,000
0
0.9
Torque (N·m)
0.6
0.3
1.2
MS1H1-10B30CB
A B
0
2,000
3,000
4,000
5,000
6,000
Speed (RPM)
1,000
0
1.8
Torque (N·m)
1.2
0.6
2.4
MS1H1-20B30CB
A B
0
2,000
3,000
4,000
5,000
6,000
Speed (RPM)
1,000
0
3.6
Torque (N·m)
2.4
1.2
4.8
MS1H1-40B30CB
A B
0
