Intel Desktop Board DH61AG Technical Product Specification
28
• Brightness Steps: allows the system integrator to configure the brightness steps
for the operating system’s “screen brightness” control (such as the “Screen
brightness” adjustment slider under the Windows 7 “Power Options” control panel).
• Flat Panel Configuration Changes Lock: allows the system integrator to “lock”
critical settings of the LVDS configuration to avoid end users potentially rendering
the display unusable.
• LVDS Interface Type: allows the system integrator to select whether the LVDS
panel is a single-channel or dual-channel display.
• Color Depth: allows the system integrator to select whether the panel is 24 bpp
with VESA color mapping (eDP and LVDS), 24 bpp with JEIDA color mapping (LVDS
only), or 18 bpp (eDP and LVDS).
• eDP Interface Type: allows the system integrator to select whether the eDP panel
is a 1-lane, 2-lane, or 4-lane display.
• eDP Data Rate: allows the system integrator to select whether the eDP panel runs
at 1.62 Gb/s or 2.7 Gb/s.
• Inverter Frequency and Polarity: allows the system integrator to set the operating
frequency and polarity of the panel inverter board.
• Maximum and Minimum Inverter Current Limit (%): allows the system integrator
to set maximum PWM%, as appropriate, according to the power requirements of
the internal flat panel display and the selected inverter board.
• Panel Power Sequencing: allows the system integrator to adjust panel sequencing
parameters, if necessary.
• LVDS Spread Spectrum Control: allows the system integrator to adjust spread
spectrum for the LVDS interface.
NOTE
Support for flat panel display configuration complies with the following:
1. Internal flat panel display connectivity is disabled (and all parameters hidden) by
default.
2. Internal flat panel display settings are not exposed through Intel
®
Integrator
Toolkit or Intel
®
Integrator Assistant GUIs.
3. Internal flat panel display settings will not be overwritten by loading BIOS setup
defaults.
4. Internal flat panel display settings will be preserved across BIOS updates.

Intel DH61AG Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16.6 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Product family	Desktop board
Product series	Intel desktop board with Intel H61 Express
Processor socket	LGA 1155 (Socket H2)
Product codename	-
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum internal memory supported by processor	16 GB
USB 2.0 connectors	3
S/PDIF out connector	1
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	Nettop
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
LAN controller	Intel® 82579V
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	3.0b
BIOS memory size	32 Mbit
Status	Discontinued
Form factor	Thin Mini-ITX
Last change	63903513
Born on date	Q2'11
Product name	Intel Desktop Board DH61AG
USB ports quantity	12
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Audio channels	8.2
Graphics output	LVDS eDP HDMI DVI-I
Motherboard ARK ID	54875
Discrete graphics card model	None
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G400445
Harmonized System (HS) code	8473301180

Weight and Dimensions

Width	172 mm
