Intex 128366NP Owner's Manual

119A
SAVE THESE INSTRUCTIONS
(119IO) RECTANGULAR ULTRA FRAME POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/17/2016
English
Page 6
PARTS REFERENCE (CONTINUED)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
REF.
NO.
DESCRIPTION
POOL SIZE & QUANTITIES
157-1/2”x78-3/4”
(400cm x 200cm)
118-1/8”x68-3/4”
(300cm x 175cm)
15’ x 9’
(457cmx274cm)
16’ x 8’
(488cm x 244cm)
18’ x 9’
(549cm x 274cm)
24’ x 12’
(732cm x 366cm)
32’ x 16’
(975cm x 488cm)
1
SINGLE BUTTON SPRING 8 8 8 8 8 14 20
2
HORIZONTAL BEAM (A) (SINGLE BUTTON SPRING INCLUDED) 2 2 2 2 2 2 2
3
HORIZONTAL BEAM (B) (SINGLE BUTTON SPRING INCLUDED) 4 2 4 4 4 8 12
4
HORIZONTAL BEAM (C) 2 2 2 2 2 2 2
5
HORIZONTAL BEAM (D) (SINGLE BUTTON SPRING INCLUDED) 2 2 2 2 2 2 2
6
HORIZONTAL BEAM (E) (SINGLE BUTTON SPRING INCLUDED) 0 2 0 0 0 2 4
7
HORIZONTAL BEAM (F) 2 2 2 2 2 2 2
8
CORNER JOINT 4 4 4 4 4 4 4
9
U-SUPPORT END CAP 24 16 24 24 24 36 48
10
DOUBLE BUTTON SPRING CLIP 24 16 24 24 24 36 48
11
U-SHAPED SIDE SUPPORT (U-SUPPORT END CAP & DOUBLE BUTTON SPRING CLIP INCLUDED) 12 8 12 12 12 18 24
12
CONNECTING ROD 12 8 12 12 12 18 24
13
RESTRAINER STRAP 12 8 12 12 12 18 24
14
GROUND CLOTH 0 0 1 1 1 1 1
15
POOL LINER (DRAIN VALVE CAP INCLUDED) 1 1 1 1 1 1 1
16
DRAIN CONNECTOR 1 1 1 1 1 1 1
17
DRAIN VALVE CAP 2 2 2 2 2 2 2
18
POOL COVER 0 0 1 1 1 1 1
19
STRAINER HOLE PLUG 3 3 3
20 PLASTIC INSERT FOR CORNER JOINT 8 8 8 8 8 8 8
21 PLASTIC INSERT FOR HORIZONTAL CORNER PIPE 8 8 8 8 8 8 8
REF.
NO.
DESCRIPTION
157-1/2”x78-3/4”x39-3/8”
(400cm x 200cm x 100cm)
118-1/8”x68-3/4”x31-1/2”
(300cm x 175cm x 80cm)
15’ x 9’ x 48’’ (457cm
x 274cm x 122cm)
16’ x 8’ x 42’’ (488cm
x 244cm x 107cm)
18’ x 9’ x 52’’ (549cm
x 274cm x 132cm)
24’ x 12’ x 52’’ (732cm
x 366cm x 132cm)
32' x 16' x 52'' (975cm
x 488cm x 132cm)
SPARE PART NO.
1
SINGLE BUTTON SPRING 10381 10381 10381 10381 10381 10381 10381
2
HORIZONTAL BEAM (A) (SINGLE BUTTON SPRING INCLUDED) 12161 12209 11524D 12219 10919D 10920D 10921D
3
HORIZONTAL BEAM (B) (SINGLE BUTTON SPRING INCLUDED) 12162 12210 11525D 12220 10922D 10923D 10924D
4
HORIZONTAL BEAM (C) 12163 12211 11526D 12221 10925D 10926DD 10927D
5
HORIZONTAL BEAM (D) (SINGLE BUTTON SPRING INCLUDED) 12164 12212 10928D 12222 10928D 10929D 10928D
6
HORIZONTAL BEAM (E) (SINGLE BUTTON SPRING INCLUDED) 12281 10930D 10931D
7
HORIZONTAL BEAM (F) 12165 12212 10932D 12223 10932D 10933D 10932D
8
CORNER JOINT 12166 12166 10934D 12224 10934D 10934D 10934D
9
U-SUPPORT END CAP 10379 10379 10935 10379 10935 10935 10935
10
DOUBLE BUTTON SPRING CLIP 10382 10382 10936 10382 10936 10936 10936
11
U-SHAPED SIDE SUPPORT (U-SUPPORT END CAP &
DOUBLE BUTTON SPRING CLIP INCLUDED)
12167 12214 11523D 12225 10937D 10937D 10937D
12
CONNECTING ROD 10383 10383 10383 10383 10383 10383 10383
13
RESTRAINER STRAP 12226 12217 10938D 12226 10938D 10938D 10938D
14
GROUND CLOTH 11521 12227 10759 18941 10760
15
POOL LINER (DRAIN VALVE CAP INCLUDED) 12135 12216 12444 12228 12445 12446 12447
16
DRAIN CONNECTOR 10201 10201 10201 10201 10201 10201 10201
17
DRAIN VALVE CAP 11044 11044 11044 11044 11044 11044 11044
18
POOL COVER 11522 12229 10756 18936 10757
19
STRAINER HOLE PLUG 10127 10127 10127
20 PLASTIC INSERT FOR CORNER JOINT 11156 11156 11156 11156 11156 11156 11156
21 PLASTIC INSERT FOR HORIZONTAL CORNER PIPE 11157 11157 11157 11157 11157 11157 11157
