English
Page 5
PARTS REFERENCE
(
continued
)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
If the pump was purchased individually, only these inlet fi tting parts are included:
If the pump was purchased as part of a pool set with 1-1/2" (38mm) connections/ hoses, below
fi tting parts are included:
If the pump was purchased as part of a pool set with 1-1/4" (32mm) connections/ hoses, below
fi tting parts are included:
NOTE:
Drawings for illustration purpose only. Actual product may vary. Not to scale.
Contact our Authorized Service Centers to order these parts if needed. When ordering parts, be
sure to quote the model number and part numbers.
44
24 25 42 2741
INLET
44
24 25 42 2741
21
22
23
21
22
23 24 25 26 40
INLET OUTLET
28 29 30
41
44
43 28 29 31
INLET OUTLET
