6B – 18 ENGINE COOLING

110RS005

• Check the rubber hoses for swelling.

Installation

1. Install radiator assembly (9) with hose, taking care not to

damage the radiator core with a fan blade.

2. Support the radiator upper tank with the bracket (5) and

secure the radiator.

3. Connect reserve tank hose (6).

4. Install lower fan guide (3).

5. Connect radiator inlet hose and outlet hose (1) to the

engine.

RTW36BMH000101

6. Connect oil cooler hose to automatic transmission.

7. Connect battery ground cable.
