SERVICE MANUAL
B-56
Step 100
Fit thermostat valve with hose pipe (water pump to thermostat and
thermostat to water return line) tighten hose clamps. Properly
Step 101
Push gently centering guide along with sealing rings 14x2 in crank case
Step103
Fit oil tube assy. With banjo bolt B-13 using sealing washer (18x24x1.5 CU)
from oil filter body to close
Step 102
Fit oil filter body on crankcase along with Gasket .Screw M10x25 screws &
mount oil filter body
