JBL CS80 User Manual

Part Number Description Qty Reference Designator
Main Amp PCB
192-022tip36c-E TRANSISTOR TIP36C (RoHS) PNP 1 Q108,
192-027c1815gr-E TRANSISTOR 2SC1815GR TOSHIBA(RoHS) 2 Q101,Q115
192-201d882y-E TRANSISTOR KSD882Y PNP 1 Q117,
192-202b772y-E TRANSISTOR KSB772Y PNP 1 Q119,
192-991d669a-E TRANSISTOR HI-SINCERITY HSD669A NPN 1 Q106,
192-992b649t-E TRANSISTOR HSB649T PNP 1 Q105,
197-00kbl405-E Bridge Diode 4A 500V KBL405(RoHS) 1 D110,
197-101n4002-E DIODE 1N4002TB (RoHS) 1 D104,
190-06m4558d-E IC OPA 4558D DUAL OP-AMP 1 U101,
Miscellaneous
162-10202001-E 26AWG 1007 200mm RED 3mm (RoHS) 1
171-udhss124d-E *relay 5A 24V UDH-SS124D(RoHS) 1 RY101,
175-1c07v01-E COUPLER 7PIN PITCH=2.5mm(RoHS) 1 P101,
175-1d02v01-E COUPLER 2PIN PITCH=3.96mm(RoHS) 1 P102,
175-1d03v01-E
COUPLER 3 PIN PITCH=3.96mm JST-VH peel off PIN (RoHS) 1 P103,
193-3m2520-E *mica piece TO-3P 25x20mm (RoHS) 2 for Q107,Q108
323-AL-00020-0LAE HEAT SINK 65*32*31 aluminium 1
351-AM03014A094-E M3*14 MACHINE SCREW crossover BLACK (RoHS) 1
352-AM03008D040-E ￠3*8 B TYPE PING SCREW Crossover, BLACK (RoHS) 4
361-FE-00051-0LAE TRANSISTOR holder 14.2*8.0*5.2t=1.6mm (RoHS) 1
361-NYL-00054-0LAE TRANSISTOR sheet (SW06002) (RoHS) 2
Input/Preamp PCB
Resistors
110-16102j26-E RESISTOR 1K 1/6W ±5% CF 26mm (RoHS) 5 R213,R214,R215,R254,R253,
110-16103j26-E RESISTOR 10K 1/6W ±5% CF 26mm (RoHS) 12
R212,R216,R217,R220,R221,R222,R225,R2
28,R226,R232,R235,R240,
110-16104j26-E RESISTOR 100K 1/6W ±5% CF 26mm (RoHS) 2 R231,R266,
110-16105j26-E RESISTOR 1M 1/6W ±5% CF 26mm (RoHS) 1 R259,
110-16122j26-E RESISTOR 1.2K 1/6W ±5% CF 26mm (RoHS) 1 R264,
110-16124j26-E RESISTOR 120K 1/6W ±5% CF 26mm (RoHS) 1 R233,
110-16153j26-E RESISTOR 15K 1/6W ±5% CF 26mm (RoHS) 1 R234,
110-16154j26-E RESISTOR 150K 1/6W ±5% CF 26mm (RoHS) 1 R251,
110-16183j26-E RESISTOR 18K 1/6W ±5% CF 26mm (RoHS) 2 R262,R227,
110-16205j26-E RESISTOR 2M 1/6W ±5% CF 26m m (RoHS) 1 R257,
110-16223j26-E RESISTOR 22K 1/6W ±5% CF 26mm (RoHS) 3 R238,R250,R255,
110-16273j26-E RESISTOR 27K 1/6W ±5% CF 26mm (RoHS) 2 R223,R237,
110-16333j26-E RESISTOR 33K 1/6W ±5% CF 26mm (RoHS) 1 R249,
110-16334j26-E RESISTOR 330K 1/6W ±5% CF 26mm (RoHS) 1 R252,
110-16472j26-E RESISTOR 4.7K 1/6W ±5% CF 26mm (RoHS) 2 R258,R260,
110-16473j26-E RESISTOR 47K 1/6W ±5% CF 26mm (RoHS) 1 R219,
110-16512j26-E RESISTOR 5.1K 1/6W ±5% CF 26mm (RoHS) 3 R211,R229,R230,
110-16513j26-E RESISTOR 51K 1/6W ±5% CF 26mm (RoHS) 1 R224,
115-h503a104-E Variable RESISTOR D16 50K/1 A (RoHS) 1 VR201,
Capacitors
130-2b221k503-E DISC CAPACITOR 220P 50V ±10% (RoHS) 9
C207,C208,C210,C211,C212,C214,C220,C2
30,C249,
130-3f104z503-E DISC CAPACITOR 0.1U 50V +80/-20% (RoHS) 7 C232,C242,C244,C245,C246,C252,C254,
130-ch220k503-E DISC CAPACITOR 22PF CH 50V±10 % (RoHS) 1 C229,
132-103j503-E MYLAR CAPACITOR 0.01uF 50V ±5% (RoHS) 2 C223,C224,
132-104j503-E MYLAR CAPACITOR 0.1U 50V ±5% (RoHS) 3 C218,C221,C222,
132-223ja03-E MYLAR CAPACITOR 0.022uF 100V ±5% (RoHS) 1 C215,
132-473j503-E MYLAR CAPACITOR 0.047U 50V ±5% (RoHS) 2 C216,C217,
135-3105m50-E ELECTROYTIC CAP.1U 50V ±20% (RoHS) 1 C228,
135-3106m50-E ELECTROYTIC CAP.10uF 50V ±20% (RoHS) 8
C206,C213,C219,C231,C241,C243,C251,
C253,
13
CS80 (CS480 Subwoofer)

JBL CS80 Specifications

General

Brand	JBL
Model	CS80
Category	Subwoofer
Language	English
