JBL ES250P User Manual

Part Number Description Qty Reference Designator
INPUT/PREAMP PCB & DAUGHTER BOARD PCB
135-3105m50-e electrolytic CAP. 1U 50V ±20% (RoHS) 1 C126,
135-3106m50-e electrolytic CAP. 10uF 50V ±20% (RoHS) 4 C109,C111,C123,C129,
135-3107m16-e electrolytic CAP. 100uF 16V ±20% (RoHS) 5 C113,C115,C132,C134,C136,
135-3107m25-e electrolytic CAP. 100U 25V ±20% (RoHS) 1 C152
135-3226m50-e electrolytic CAP. 22U 50V ±20% (RoHS) 1 C151
139-3227m16-e LOW LEAKAGE EC 220uF 16V±20% (RoHS) 1 C131
129-a473j633-e metalize CAP. 0.047U 63V ±5% MSC (RoHS) 1 C150,
Semiconductors
192-027c1815gr-e transistor 2SC1815GR TOSHIBA(RoHS) NPN 3 Q101,Q102,Q103,
197-631n4148-e DIODE 500mW 75V 1N4148 Panjit (RoHS) 7 D105,D106,D108,D109,D110,D112,D113
199-55000395-e ZENER DIODE 3.9V 1/2W 52mm (RoHS) 1 D130
192-153j111-e FET J111 FAIRCHILD TO-92 (RoHS) 1 Q107,
190-06m4558d-e I.C. OPA 4558D (RoHS) DUAL OP-AMP 2 U101,U103,
190-16tl072n-e I.C. TL072N @6.5 (RoHS) DUAL OP-AMP 1 U105,
190-16tl074cn-e I.C TL074CN ST (RoHS) QUAD OP-AMP 2 U102,U106,
Miscellaneous
162-10169003-e WIRE ASS'Y 160mm AWG28 WHT/BLK(RoHS) 1 P105,
162-50122004-e WIRE ASS'Y 120mm RED/WHT 2PIN (RoHS) 1 D201,
174-0rcb202vag-e RCA JACK RCA-209 WITH GOLD (RoHS) INPUT 1 JK102,
175-1c02v01-e WIRE CONNECTOR&BASE 2PIN PITCH=2.5mm (RoHS) 1 P106,
175-9f40hr2-e WIRE CONNECTOR&BASE 40PIN PITCH=2.54mm HR2*40 (
R
0.5 D201,
180-T000TS81-E
TACT SWITCH T2 T8019L-SNQ-E-H+U PHASE, LFE/NORMAL 2 SW102,SW103,
362-FE-00041-0LAE PCB SUPPORT 11.75*8.5*12.5H (RoHS) 1
MAIN PCB
Resistors
110-16102J26-E carbon resistor 1K 1/6W ±5% CF (RoHS) 3 R210,R239,R264,
110-16103J26-E carbon resistor10K 1/6W ±5% CF (RoHS) 9
R216,R227,R229,R230,R231,R232,R233,
R260,R261,
110-16153j26-e carbon resistor15K 1/6W ±5% CF (RoHS) 2 R247,R249,
110-16182j26-e carbon resistor 1.8K 1/6W ±5% CF (RoHS) 1 R248,
110-16222J26-E carbon resistor2.2K 1/6W ±5% CF (RoHS) 2 R242,R245,
110-16223J26-E carbon resistor 22K 1/6W ±5% CF (RoHS) 3 R218,R220,R223,
110-16274j26-e carbon resistor 270K 1/6W ±5% CF (RoHS) 1 R240,
110-16333j26-e carbon resistor 33K 1/6W ±5% CF (RoHS) 1 R211,
110-16391j26-e carbon resistor 390Ω 1/6W CF (RoHS) 2 R243,R246,
110-16472J26-E carbon resistor4.7K 1/6W ±5% CF (RoHS) 4 R213,R217,R219,R222,
110-16473J26-E carbon resistor 47K 1/6W ±5% CF (RoHS) 1 R221,
110-16683j26-e carbon resistor 68K 1/6W ±5% CF (RoHS) 1 R212,
112-14101j26-e fuse resistor 1/4W100ohm 5% (RoHS) 2 R241,R244,
116-141r00j26x-e metal film resistor 1.00Ω 1/4W±5% MO (fireproofing resistor ) 2 R255,R256,
116-161002f26-e metal film resistor 10K 1/6W ±1% MF (RoHS) 2 R234,R235,
116-161301f26-e metal film resistor 1.30K 1/6W MF (RoHS) 3 R226,R228,R236,
116-161692f26-e metal film resistor 16.9K 1/6W MF (RoHS) 1 R214,
116-162001f26-e metal film resistor 2.00K 1/6W ±1% MF (RoHS) 1 R215,
116-162492f26-e metal film resistor 24.9K 1/6W ±1% MF (RoHS) 2 R257,R258,
116-166813f26-e metal film resistor 681K 1/6W ±1% MF (RoHS) 1 R262,
110-12621j15-e Carbon resistor 620Ω 1/2W ±5% 15mm (RoHS) 1 R238,
110-20152j20-e Carbon resistor 1.5K 2W ±5% CF 20mm KINK 1 R208,
113-50r10j10-e CEMENT RESISTOR 0.1Ω 5W ±5% (RoHS) 2 R224,R225,
116-142003f26-e metal film resistor 200K 1/4W ±1% MF 1 R209,
Capacitors
135-4228m35-e electrolytic CAP. 2200uF 35V ±20% 2 C170,C171,
135-4688m80-e electrolytic CAP. 6800U 80V ±20%(RoHS) 2 C168,C169,
130-2b102k503-e Disc Capacitor 1000P 50V ±10% (RoHS) 1 C165,
19
ES250P
