JBL GT1041D User Manual

VENTED BOX VOLUME
(INCLUDES DRIVER/PORT DISPLACEMENTS)
VENTED
FREQUENCY RESPONSE @ 2.83 V
VENTED
EXCURSION/GROUP DELAY @ 275 W
SEALED BANDPASS BOX VOLUME
(INCLUDES DRIVER/PORT DISPLACEMENTS)
SEALED BANDPASS
FREQUENCY RESPONSE @ 2.83 V
SEALED BANDPASS
EXCURSION/GROUP DELAY @ 275 W
Harman Consumer Group • 250 Crossways Park Drive • Woodbury, NY 11797 • VOICE: 516-496-3400 • FAX: 516-496-4868 • www.jbl.com
GT1041D 10" Woofer – Technical Data
GT1041D
(side view)
Port
f
o
= 33.0Hz
diameter = 3 "
length = 9.00"
V
BOX
= 1.25 ft
3
(35.40 liters)
(all sides lined with 1-inch fiberglass or fiberfill)
C
dB
105
100
95
90
85
80
75
70
65
20 Frequency 50 100 Hz 200 500 1k 2 k
Out-Of-Car
In-Car
12 dB LP @ 80 Hz
C
Xd mM
40
35
30
25
20
15
10
5
0
T mSec
40
30
20
10
0
-10
-20
-30
-40
20 Frequency 50 100 Hz 200 500 1k 2 k
Transducer Excursion
Group Delay
V
REAR
= 1.00 ft
3
(28.32 liters)
(all sides lined with 1-inch fiberglass or fiberfill)
V
FRONT
= 0.75 ft
3
(21.24 liters)
GT1041D
(side view)
diam. = 4"
Port
f
o
= 65.0 Hz
length =
5.50"
C
dB
100
95
90
85
80
75
70
65
60
20 Frequency 50 100 Hz 200 500 1k 2 k
Out-Of-Car
In-Car
12 dB LP @ 90 Hz
C
Xd mM
20.0
17.5
15.0
12.5
10.0
7.5
5.0
2.5
0.0
T mSec
20
15
10
5
0
-5
-10
-15
-20
20 Frequency 50 100 Hz 200 500 1k 2 k
Transducer Excursion
Group Delay

JBL GT1041D Specifications

General

Brand	JBL
Model	GT1041D
Category	Subwoofer
Language	English
