JBL GT1200 User Manual

V
BOX
= 1.20 ft
3
(33.98 liters)
(all sides lined with 1-inch fiberglass or fiberfill)
GT1200
(side view)
C
dB
100
95
90
85
80
75
70
65
60
20 Frequency 50 100 Hz 200 500 1k 2 k
Out-Of-Car
In-Car
12 dB LP @ 90 Hz
C
Xd mM
20.0
17.5
15.0
12.5
10.0
7.5
5.0
2.5
0.0
T mSec
10.0
7.5
5.0
2.5
0.0
-2.5
-5.0
-7.5
-10.0
20 Frequency 50 100 Hz 200 500 1k 2 k
Transducer Excursion
Group Delay
GT1200
(side view)
Port
f
o
= 30 Hz
diameter = 4.0"
length = 14.00"
V
BOX
= 1.80 ft
3
(50.98 liters)
(all sides lined with 1-inch fiberglass or fiberfill)
C
dB
105
100
95
90
85
80
75
70
65
20 Frequency 50 100 Hz 200 500 1k 2 k
Out-Of-Car
In-Car
12 dB LP @ 90 Hz
C
Xd mM
20.0
17.5
15.0
12.5
10.0
7.5
5.0
2.5
0
T mSec
20
15
10
5
0
-5
-10
-15
-20
20 Frequency 50 100 Hz 200 500 1k 2 k
Transducer Excursion
Group Delay
SEALED
BOX VOLUME
SEALED
FREQUENCY RESPONSE @ 2.83 V
SEALED
EXCURSION/GROUP DELAY @ 250 W
VENTED
BOX VOLUME
VENTED
FREQUENCY RESPONSE @ 2.83 V
VENTED
EXCURSION/GROUP DELAY @ 275 W
GT1200 12" Woofer – Technical Data
JBL Technical Data . . . . . 7•21

JBL GT1200 Specifications

General

Brand	JBL
Model	GT1200
Category	Subwoofer
Language	English
