JBL GTO 75.4 Service Manual

RES-00-01046 RESISTOR MOR/S 2WJ (15m/m FORMING) 100 OHM R30 1
RES-00-01264 RESISTOR MOR/S 2WJ (15m/m FORMING) 150 OHM R291 1
RES-00-01265 RESISTOR MOR/S 2WJ (17.5m/m FORMIN
G150 OHM R191 1
RES-00-01041 RESISTOR MOR/S 2WJ (15m/m FORMING) 680 OHM R162,262,362,462 4
RES-00-00895 RESISTOR
WIRE WOUND 3WJ(FORMING 20m/m
0.1 OHM R160,170,260,270,360,370,460,470 8
THS-00-00013 THERMISTOR NTC RESISTOR FTD5-350 TH01 1
ELC-00-00234 CAPACITOR ELECTROLYTIC "SMS" 470/50V (12.5x20m/m) C51,61 2
DIO-00-00278 LED RED COLOR HNRD-3401L LED01 1
DIO-00-00303 LED BLUE COLOR TOL-30aSBaCAa-B2 LED02 1
ELC-00-00727 CAPACITOR ELECTROLYTIC "WL" 2200/25V (16x25m/m) C04,05,06 3
ELC-00-00714 CAPACITOR ELECTROLYTIC "HC" 4700/50V (25x30m/m) C52,62 2
COR-TF-00386 CORE
4(0.7x15):11(0.7x4):8(0.7x1):8(0.7x1)
44PHI MAGNETICS T01 1
COI-00-00093 INDUCTOR DRUM COIL CL-510 L01,02 2
COI-00-00028 INDUCTOR BAR COIL CL-310 L03 1
SWI-00-00024 SWITCH SLIDE SWITCH JSS-2219 SW102,302 2
JAC-00-00043 RCA JACK GOLD PLATED DJB-554A RCA101 1
JAC-00-00042 RCA JACK GOLD PLATED DJB-562D RCA301 1
TER-00-00241 TERMINAL GOLD PLATED DST0013-00 (3P) TER01 1
TER-00-00251 TERMINAL GOLD PLATED 2! 8P ST-11A-2-8P TER02 1
JUP-00-00005 JUMPER METAL JUMPER 55m/m BJ01,02,03,07 4
JUP-00-00003 JUMPER METAL JUMPER 35m/m BJ04,05,06 3
HOD-00-00011 FUSE HOLDER WF-9604 FH01 1
CON-00-00128 WAFER LAD1140-04PBK HI101,301 2
WIR-00-00208 WIRE ASS'Y 300m/m CHD1140-04PBK ACCESSORY 2
WIR-00-00015 WIRE
AWG #22 BK 3.2PHI RING LUG
60m/m W1,2 2
HED-00-00115
HEADER PIN SOCKET TM2501-DG-14P 14P CON101-1,301-1 2
TUB-00-00008 TEFLON TUBE 0.7PHI 10m/m TH01,Q140,240,340,440 6
TUB-00-00009 TEFLON TUBE 0.7PHI 15m/m LED02 2
TUB-00-00006 TEFLON TUBE 0.7PHI 20m/m LED01 2
FUS-AT-00006 AUTO FUSE 30A SET2+ACCESSORY2 4
PCB-00-01355 P.C.B
FR-4 DOUBLE LAYER, 1Oz BROWN
PAS319-01 148x92m/m 1
ICO-00-00113 I.C DUAL OP AMP "SOP-08" NJM2068M U102,103,104,105,302,303,304,305,306,307 10
RES-08-00239 RESISTOR
SMD 0805 1/8WF 9.31K OHM R257,457
2
RES-08-00022 RESISTOR
SMD 0805 1/8WF 15K OHM R155,255,355,455
4
RES-08-00088 RESISTOR
SMD 0805 1/8WF 47K OHM R256,456
2
RES-08-00117 RESISTOR
SMD 0805 1/8WF 91K OHM R156,356
2
RES-08-00225 RESISTOR
SMD 0805 1/8WJ 820 OHM R108,208,308,408
4
RES-08-00148 RESISTOR
SMD 0805 1/8WJ 1K OHM R391,392,491,492
4
RES-08-00201 RESISTOR
SMD 0805 1/8WJ 5.6K OHM R113,115,213,215,313,315,413,415
8
RES-08-00210 RESISTOR
SMD 0805 1/8WJ 6.8K OHM R396,496
2
RES-08-00132 RESISTOR
SMD 0805 1/8WJ 10K OHM R110,111,112,114,210,211,212,214,310,311
16
R312,314,410,411,412,414
RES-08-00187 RESISTOR
SMD 0805 1/8WJ 39K OHM R393,493
2
RES-08-00141 RESISTOR
SMD 0805 1/8WJ 150K OHM R397,497
2
CEC-08-00009 CAPACITOR
SMD 0805 12pF C156,356
2
CEC-08-00017 CAPACITOR
SMD 0805 20pF C256,456
2
CEC-08-00042 CAPACITOR
SMD 0805 47pF C111,211,311,393,411,493
6
CEC-08-00040 CAPACITOR
SMD 0805 473pF C195,196,295,296,395,396,495,496
8
MYC-00-00157 CAPACITOR MYLAR 5% 63V "TL"
823J C113,115,213,215,313,315,413,415
8
MYC-00-00083 CAPACITOR MYLAR 5% 63V "TL"
104J C391,392,491,492
4
ELC-00-00241
CAPACITOR ELECTROLYTIC"SRE"
10/16V C125,155,225,255,325,355,425,455 8
SWI-00-00112 SWITCH
SLIDE SWITCH JSS2301S120 SW101,301
2
VOL-00-00337 VOLUME
V123H CO 20RS B20K (10%) 20KBx2 VR101,301,303
3
VOL-00-00338 VOLUME
V124H CO 20RS C50K (10%) 50KCx4 VR102,302
2
HED-00-00245 PIN CONNECTOR
TM2008-D81G-14P 14P CON101,301
2
GTO 75.4/75.4II
18

JBL GTO 75.4 Specifications

General

Brand	JBL
Model	GTO 75.4
Category	Amplifier
Language	English
