JBL Horizon Service Manual

MECHANICAL AND ELECTRICAL PARTS LIS
T
P/N DESCRIPTION
QTY
POS. No.
20180175080001 SPEAKER 1.75" 8Ohm*8W 2 5
24104830901049 JBLHORIZON EU BATTERY COVER BLK 1 57
24104830902049 JBLHORIZON EU BATTERY COVER WHT 1 57
24104831001049 JBLHORIZON EU SET BUTTON BLK 1 35
24104831002049 JBLHORIZON EU SET BUTTON WHT 1 35
24104831101049 JBLHORIZON EU DST BUTTON BLK 1 48
24104831102049 JBLHORIZON EU DST BUTTON WHT 1 48
24104831301049 JBLHORIZON EU USB COVER BLK 1 41
24104831301049 JBLHORIZON EU USB COVER WHT 1 41
24104831801029 DISPLAY LENS 1
20700100020019 BUZZER SEA-12085-42 1 B1
311048301009
MAIN BOARD 1 18
993104830119 MAIN BOARD 1 18
232200036019 FM MODULE AP420 1 U14
232600041109 BT MODULE BM830 PROGRAMMED unitec 1 U5
403100040209 IC LM358 SOP8 1 U11
403200140109 ALPHA-SEMIC AS1117-3.3 SOT-223 1 U6
403200140119 AS1117-5.0 SOT-223 TR-LF 1 U15
403500020289 CMOS 4 4052 SOP16 1 U13
403901690109 IC MC4558 SOP 1 U2
403902180189 IC MP1470 TSOT23-6PIN DCtoDC 1 U19
403902570909 IC AS2930-3.3V SOT23-5 1 U25
403902690219 IC PCF8563T SO8 1 U1
403903511009 IC ESDA0603-05-5.5V 5pF +30-20 SMD0603 9 ESD1-ESD9
403903600509 IC INVERTER SN74LVC1GU0 4DCKR SC70-5 1 U10
403903780109 IC AK5358A A/D TSSOP16 1 U9
403904600109 IC TAS5709 HTQFP-48 1 U18
403904610109 IC MP1495 TSOT-23-8PIN 1 U17
403904620219 IC ASM32 MO16GA MCU LPFQ-48 1 U4
403904630109 IC G524B1T11U SOT23-5 1 U21
311048302009
SNOOZE BOARD 1 16
311048303009 KEY BOARD 1 14
993104830309 ASSY. KEY BOARD 14+16
311048304009
LED LAMP BOARD 1 12
993104830409 LED LAMP BOARD 1 12
405400050129 LED DIODE white 10
311048305009
USB BOARD 1 39
993104830509 USB BOARD WHT 1 39
993104830519 USB BOARD BLK 1 39
311048306009
INPUT BOARD 1 32
993104830609 INPUT BOARD 1 32
311048307009
Horizon LCD BOARD 1
993104830719 Horizon LCD BOARD 1
403900050109 IC HT1621B SSOP48 2 U22,U24
411000260109 LCD 56PIN 4.5V 84*51.5MM WITH BACKLIGHT 1 2
993104830819 EU BATTERY BOARD WHT 1 23
993104830809 EU BATTERY BOARD BLK 1 23
24104831201049 BATTERY HOUSING 1 21

JBL Horizon Specifications

General

Radio type	Clock
Tuner type	Digital
PLL synthesizer	-
Supported radio bands	FM
RMS rated power	10 W
Number of built-in speakers	1
Display type	LCD
MP3 playback	No
Product color	Black
Input voltage	12 V
Apple docking compatibility	Not supported
AC input frequency	70 - 20000 Hz

Weight and Dimensions

Depth	86 mm
Width	183 mm
Height	160 mm
Weight	890 g
