© 2015 HARMAN International Industries, Incorporated. All rights reserved.
JBL is a trademark of HARMAN International Industries, Incorporated registered in the United States and/or other countries.
HARMAN International Industries, Inc.
8500 Balboa Boulevard, Northridge,
CA 91329 USA
www.jbl.com
IMPORTANT: Make sure the
subwoofer amplifier is turned OFF before
setting the SSI switch. Do not change the
switch position while the subwoofer
amplifier is operating. Doing so could
damage the amplifier.
CONNECTING THE
AMPLIFIER
The subwoofer connectors are compatible
with bare or tinned wires. The
recommended wire gauge is between
14AWG and 8AWG, depending on the length
of the wire run between the amplifier and
woofer. Heavier gauge wire is preferred
for runs over 6' (2m).
1.Use a 2.5 mm hex driver to open the
connectors
2.Insert the wire ends into the connector
openings
NOTE: If using untinned bare wire, be sure that
no stray “+” and “–” strands touch each other.
Touching strands can cause a short-circuit,
which can damage your amplifier.
3.Use the hex driver to secure the wires in the
connectors, as shown in the illustration
to the left
1. Use hex wrench to open connectors
3. Use hex wrench to secure connectors
2. Insert wires
into connector
openings
mounting depth
6-15/16" (175mm)
cutout diameter
9-7/16" (239mm)
outer diameter
11" (279mm)
DIAMETER: 10" (254MM)
S
ENSITIVITY (2.83V @ 1M): 91dB
P
OWER HANDLING: 450W RMS (1350W PEAK)
F
REQUENCY RESPONSE: 30HZ ~ 175HZ
NOMINAL 2 OR 4 OHMS
VOICE-COIL DIAMETER: 2 1/2" (63MM)
D
IMENSIONS:
V
ENTED-BOX VOLUME (INCLUDES DRIVER/PORT DISPLACEMENTS)
S
EALED-BOX VOLUME (INCLUDES DRIVER DISPLACEMENT)
S
PECIFICATIONS
V
BOX
= 0.50 ft
3
(14.20 liters)
(side view)
Port
f
B
= 30.0Hz
diameter = 3"
76mm
length = 11.3"
287mm
V
BOX
= 1.5 ft
3
(42.5 liters)
(side view)
VOICE-COIL DC RESISTANCE: R
EVC
(OHMS) . . . . . . . . 1.80 . . . . . . . . . 4.06
V
OICE-COIL INDUCTANCE @ 1KHZ: L
EVC
(MH) . . . . . . . . . 1.04 . . . . . . . . . 0.91
D
RIVER RADIATING AREA: S
D
(IN
2
) . . . . . . . . . . 53.69 . . . . . . . . 53.69
S
D
(CM
2
). . . . . . . . . 346.36 . . . . . . . 346.36
M
OTOR FORCE FACTOR: BL
. . . . .. . . . . 10.54 . . . . . . . . 14.98
C
OMPLIANCE VOLUME: V
AS
(FT
3
) . . . . . . . . . . 0.86 . . . . . . . . . 0.89
V
AS
(LITERS) . . . . . . . 24.22 . . . . . . . . 25.27
S
USPENSION COMPLIANCE: C
MS
(µM/N) . . . . . . 144.00 . . . . . . . 150.00
M
OVING MASS, AIR LOAD: M
MS
(GRAMS). . . . . . 188.72 . . . . . . . 185.47
F
REE-AIR RESONANCE: F
S
(HZ) . . . . . . . . . . 30.56 . . . . . . . . 30.18
M
ECHANICAL Q: Q
MS
. . . . . . . . . . . . . . 3.11 . . . . . . . . . 2.17
E
LECTRICAL Q: Q
ES
. . . . . . . . . . . . . . 0.57 . . . . . . . . . 0.61
T
OTAL Q: Q
TS
. . . . . . . . . . . . . . 0.48 . . . . . . . . . 0.48
M
AGNETIC-GAP HEIGHT: H
AG
(IN) . . . . . . . . . . . 0.39 . . . . . . . . . 0.39
H
AG
(MM) . . . . . . . . . 10.00 . . . . . . . . 10.00
V
OICE-COIL HEIGHT: H
VC
(IN) . . . . . . . . . . . 1.32 . . . . . . . . . 1.32
H
VC
(MM) . . . . . . . . . 33.50 . . . . . . . . 33.50
M
AXIMUM EXCURSION: X
MAX
(IN) . . . . . . . . . . 0.47 . . . . . . . . . 0.47
X
MAX
(MM) . . . . . . . . 12.00 . . . . . . . . 12.00
2Ω 4Ω
TECHNICAL DATA
mounting depth
7" (177mm)
cutout diameter
11-1/8" (282mm)
outer diameter
12-13/16" (324mm)
TR00496_A
DIAMETER: 12" (305MM)
S
ENSITIVITY (2.83V @ 1M): 92dB
P
OWER HANDLING: 500W RMS (1500W PEAK)
F
REQUENCY RESPONSE: 25HZ ~ 175HZ
NOMINAL IMPEDANCE: 2 OR 4 OHMS
VOICE-COIL DIAMETER:
D
IMENSIONS:
V
ENTED-BOX VOLUME (INCLUDES DRIVER/PORT DISPLACEMENTS)
S
EALED-BOX VOLUME (INCLUDES DRIVER DISPLACEMENT)
S
PECIFICATIONS
V
BOX
= 0.75 ft
3
(21.20 liters)
(side view)
Port
f
B
= 30.0Hz
diameter = 4"
102mm
length = 11.7"
298mm
V
BOX
= 2.5 ft
3
(70.8 liters)
(side view)
THIELE-SMALL PARAMETERS
VOICE-COIL DC RESISTANCE
EVC
(OHMS) . . . . . . . . 1.82 . . . . . . . . . 4.07
V
OICE-COIL INDUCTANCE @ 1KH
EVC
(MH) . . . . . . . . . 1.03 . . . . . . . . . 0.94
D
RIVER RADIATING AREA
D
(IN
2
) . . . . . . . . . . 82.29 . . . . . . . . 82.29
S
D
(CM
2
). . . . . . . . . 530.93 . . . . . . . 530.93
M
OTOR FORCE FACTOR: . . . . . . . . . 11.70 . . . . . . . . 16.99
C
OMPLIANCE VOLUME: V
AS
(FT
3
) . . . . . . . . . . 1.93 . . . . . . . . . 1.86
V
AS
(LITERS) . . . . . . . 54.65 . . . . . . . . 52.59
S
USPENSION COMPLIANCE
MS
(µM/N) . . . . . . 138.00 . . . . . . . 133.00
M
OVING MASS, AIR LOAD
MS
(GRAMS). . . . . . 220.58 . . . . . . . 225.64
F
REE-AIR RESONANCE: F
S
(HZ) . . . . . . . . . . 28.84 . . . . . . . . 29.07
M
ECHANICAL Q: Q
MS
. . . . . . . . . . . . . . 4.29 . . . . . . . . . 2.56
E
LECTRICAL Q: Q
ES
. . . . . . . . . . . . . . 0.53 . . . . . . . . . 0.58
T
OTAL Q: Q
TS
. . . . . . . . . . . . . . 0.47 . . . . . . . . . 0.47
M
AGNETIC-GAP HEIGHT
AG
(IN) . . . . . . . . . . . 0.39 . . . . . . . . . 0.39
H
AG
(MM) . . . . . . . . . 10.00 . . . . . . . . 10.00
V
OICE-COIL HEIGHT: H
VC
(IN) . . . . . . . . . . . 1.32 . . . . . . . . . 1.32
H
VC
(MM) . . . . . . . . . 33.50 . . . . . . . . 33.50
M
AXIMUM EXCURSION: X
MAX
(IN) . . . . . . . . . . 0.47 . . . . . . . . . 0.47
X
MAX
(MM) . . . . . . . . 12.00 . . . . . . . . 12.00
2Ω 4Ω
S3-1024 S3-1224
2 1/2" (63MM)
THIELE-SMALL PARAMETERS
(T
M
) BL (T
M
)
mounting height
3/4" (18 mm)
mounting height
3/4" (18 mm)
IMPEDANCE:
