JBL JRX215 User Manual

SSJRX215
CRP
06/13
䉴 JRX215 15 Inch Two-Way Sound Reinforcement Loudspeaker System
TIP
TIP
GRD
GRD
+
-
+
-
HPF
LPF
1-
1-
1+
1+
20 100 1000 10000 20000
Frequency (Hz)
70
80
90
100
110
SPL (dB)
20 100 1000 10000 20000
Frequency (Hz)
0
10
20
1
10
100
Directivity Index (DI), dB
Directivity Factor (Q)
20 100 1000 10000 20000
Frequency (Hz)
10
100
360
-6 dB Beamwidth (degrees)
Horizontal
Vertical
294
(11.6)
391
(15.4)
686
(27.0)
699
(27.5)
7.5°
432
(17.0)
460
(18.1)
353
(13.9)
368
(14.5)
220
(8.7)
319
(12.6)
69
(2.7)
97
(3.8)
226
(8.9)
138
(5.4)
32
(1.3)
32
(1.3)
32
(1.3)
32
(1.3)
184
(7.3)
230
(9.1)
162
(6.4)
101
(3.9)
53
(2.1)
Dimensions
Dimensions in mm (in)
JBL Professional
8500 Balboa Boulevard, P.O. Box 2200
Northridge, California 91329 U.S.A.
© Copyright 2013 JBL Professional
www.jblpro.com
81330_JBL_JRX215_81330_JBL_JRX215 6/4/13 1:09 PM Page 2

JBL JRX215 Specifications

General

Product color	Black
Housing material	MDF
Recommended usage	Universal
Suitable for outdoor use	-
Tweeter	Yes
Speaker type	2-way
Speaker placement	Ceiling-mountable, Floor, Wall-mountable
Audio output channels	1.0 channels
Impedance	8 Ω
Sensitivity	99 dB
Frequency range	59 - 13000 Hz
RMS rated power	250 W
Crossover frequency	2200 Hz
Peak Music Power Output (PMPO)	100 W
Speaker depth	432 mm
Speaker width	460 mm
Speaker height	699 mm
Speaker weight	27400 g
Speakon ports quantity	1
Connectivity technology	Wired
